Eaton FAZ-D2.5/1 Miniature Circuit Breaker — 1P, Type D, 2.5 A, 15 kA
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton FAZ-D2.5/1 miniature circuit breaker (MCB) from the xEffect FAZ range. 1-pole, rated current In = 2.5 A, Type D tripping characteristic. Rated ultimate short-circuit breaking capacity Icu = 15 kA to IEC/EN 60947-2; rated operational voltage Ue 230/400 V AC. DIN-rail (35 mm) modular device for overload and short-circuit protection of cables and equipment. Conforms to IEC/EN 60947-2. Eaton type FAZ-D2.5/1, EAN 4015082785734, Eaton/SAP material 1200237006, catalogue code 82233172.
Technical Specifications
- Manufacturer
- Eaton
- Product family
- xEffect FAZ
- Type designation
- FAZ-D2.5/1
- Manufacturer part number (MPN)
- FAZ-D2.5/1
- EAN / GTIN
- 4015082785734
- Eaton / SAP material no.
- 1200237006
- Poles
- 1P
- Tripping characteristic
- Type D
- Rated current In
- 2.5 A
- Rated ultimate breaking capacity Icu
- 15 kA
- Rated operational voltage Ue
- 230/400 V AC
- Mounting
- DIN rail (35 mm)
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 4015082785734
- SAP 1200237006
- Code 82233172
