Eaton
BUSBAR 2-Phase 1P+HJ.CONNECTOR
Part numberZ-GV-16/1P+N+HS-TEAN / GTIN4015082710828HS code8536.90
Electrical Components
Busbar Systems
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Eaton Z-GV-16/1P+N+HS-T Busbar 2-Phase 1P+Auxiliary Contact akt.
Technical Specifications
- Manufacturer part number (MPN)
- Z-GV-16/1P+N+HS-T
- EAN / GTIN
- 4025221039048
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Eaton catalogue number
- 271082
- Depth
- 21 mm
- Height
- 24.4 mm
- Width
- 1010 mm
- Weight
- 0.45 kg
- Compliances
- RoHS conform
- Features
- Can be cut to size
- Electric connection type
- Fork
- Rated surge voltage
- 4 KV
- Rated uninterrupted current (Iu)
- 80 A
- Suitable for number of devices
- 0
- Number of poles
- Two-pole
- Color
- Other
- Cross section
- 16 mm²
- Number of modular spacings
- 57
- Number of phases
- 2
- Pitch dimensions
- 17.8 mm
- Rated operational voltage (Ue) - max
- 415 V
- Rated conditional short-circuit current (Iq)
- 25 kA
- Colour
- Grey
- Insulated
- No
- Rated permanent current Iu
- 80 A
- Length
- 21 mm
- Conditioned rated short-circuit current Iq
- 25 kA
- Width in number of modular spacings
- 57
- Type of electric connection
- Fork
- Suitable for devices with auxiliary switch
- No
- Suitable for devices with N-conductor
- No
- Max. rated operation voltage Ue
- 415 V
- Module width
- 17.8 mm
- Can be cut to size
- Yes
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4025221039048
- SAP 1000077765
- Code 8821335
Product Documentation
Document preview: SAMLESK. 2-FAS 1P+HJ.CONNECTOR (Z-GV-16/1P+N+HS-T) — Specification Data Sheet (OEM)
