Residual current circuit breaker with overcurrent 10A 3P C 30MAA (PKPM3-10/3/C/003-A)

Eaton PKPM3-10/3/C/003-A Residual current circuit breaker with overcurrent, C-characteristic (G)/A-type 3-pole, 10 A, 30mA, red.

Manufacturer part number (MPN)

PKPM3-10/3/C/003-A

EAN / GTIN

4015081079520

HS code

8536.90

Sales unit

pcs

Package quantity

30 pcs

Eaton catalogue number

108326

Depth

86 mm

Height

75 mm

Width

73 mm

Weight

0.39 kg

Compliances

CE Marked; RoHS conform

Certifications

CE

Voltage rating

400 V

Surge current capacity

0.25 kA

Voltage type

AC

Width in number of modular spacings

4

Operating ambient temperature - max

40 °C

Operating ambient temperature - min

-25 °C

Product application

Switchgear for industrial and advanced commercial applications

Product range

PKPM3

Rated current

10 A

Rated operational current for specified heat dissipation (In)

10 A

Rated switching capacity (IEC/EN 61009)

10 kA

Static heat dissipation, non-current-dependent

0 W

Tripping characteristic

C

Built-in depth

70 mm

Current limiting class

3

Rated short-circuit breaking capacity (EN 60947-2)

0 kA

Ambient operating temperature - max

40 °C

Ambient operating temperature - min

-25 °C

Fault current rating

0.03 A

Heat dissipation capacity

0 W

Heat dissipation per pole, current-dependent

0 W

Number of poles (protected)

3

Number of poles (total)

3

Rated operational voltage (Ue) - max

400 V

Rated switching capacity

10 kA

Basic function

Combined RCD/MCB devices

Mounting Method

DIN rail

Equipment heat dissipation, current-dependent

6.3 W

Rated impulse withstand voltage (Uimp)

4 kV

Degree of protection

IP20

Tripping

Non-delayed

Overvoltage category

III

Pollution degree

2

Impulse withstand current

Partly surge-proof, 250 A

Leakage current type

A

Release characteristic

C

Sensitivity type

Type A, pulse-current sensitive

Frequency rating

50 Hz

Rated insulation voltage (Ui)

500 V

Connectable conductor cross section (solid-core) - min

1 mm²

Connectable conductor cross section (solid-core) - max

25 mm²

Connectable conductor cross section (multi-wired) - min

1 mm²

Connectable conductor cross section (multi-wired) - max

25 mm²

Rated short-circuit breaking capacity (EN 61009)

10 kA

Rated short-circuit breaking capacity (EN 61009-1)

10 kA

Number of poles

Three-pole

Disconnection characteristic

Undelayed

Type

RCBO

Application

Switchgear for residential and commercial applications

HS Code

8536.90
