Switch-Disconnector 400A NH2 M10

Eaton XNH2-S400 NH fuse-switch 3p flange connection M10 max. 240 mm², busbar 60 mm, NH2.

Manufacturer part number (MPN)

XNH2-S400

EAN / GTIN

4015081779925

HS code

8536.90

Sales unit

pcs

Eaton catalogue number

183065

Depth

306 mm

Height

160 mm

Width

210 mm

Weight

3.329 kg

Compliances

RoHS conform

Certifications

IEC/EN 60947-3

Features

Halogen free; Standard sealable

Flammability characteristics (UL)

Self-extinguishing (UL 94)

Special features

Permanent operation (rated operating mode) Current paths of electrolytic copper, silver-plated Cable connection optionally at the top or bottom

Suitable for

Busbar mounting; Front mounting

Actuator type

Cover grip

Color

Gray

Number of poles

Three-pole

Type

Basic device

Ambient operating temperature details

Ambient temperature range: -25 °C - 70 °C

Equipment heat dissipation, current-dependent

22 W

Heat deflection temperature

125 °C

Heat dissipation at 80% without fuses

22.9 W

Heat dissipation per pole, current-dependent

7.3 W

Rated operational current for specified heat dissipation (In)

400 A

Total heat dissipation without fuses at Ith

36 W

Creepage resistance

CTI 600

Direction of incoming supply

As required (FLEX System)

Electrical connection type of main circuit

Screw connection

Frequency rating

40 Hz - 60 Hz

Frequency rating of contacts

40 Hz - 60 Hz

Lifespan, electrical

200 operations

Operating altitude without derating - max

2000 mm

Overvoltage category

III

Permitted power loss per fuse link - max

34 W

Pollution degree

3

Power rating at AC-23, 400 V

0 kW

Rated conditional short-circuit rating

100 kA (690 V); 120 kA (500 V)

Rated impulse withstand voltage (Uimp)

8 kV

Rated insulation voltage (Ui)

800 VAC

Rated operating voltage (Ue) at AC - max

690 V

Rated operation current (Ie)

400 A

Rated operational current

400 A (AC-22B); 400 A (AC-21B); 400 A (AC-23B); 400 A (DC-22B)

Rated short-time withstand current (Icw)

3 kA

Rated uninterrupted current (Iu)

400 A

Voltage rating at AC

400 V (AC-23B) 500 V (AC-22B) 690 V (AC-21B)

Voltage rating at DC

400 V (AC-23B) 500 V (AC-22B) 690 V (AC-21B)

Voltage test

Yes, sliding inspection windows

Conditioned rated short-circuit current Iq

120 kA

Rated conditional short-circuit current (Iq)

120 kA

Activation type

Dependent manual activation

Actuator position

Front side

Cable entry type

Other

Degree of protection (front side)

Other

Lifespan, mechanical

800 operations

Locking facility

Yes, optional

Material

Polyamide

Mounting method

Busbars of 60 mm

Mounting position

Vertical or horizontal

Size

NH2 fuse

Suitable for fuses

NH2

Terminal capacity (copper band)

10 mm x 16 mm x 0.8 mm (10x) at box terminal

Terminal capacity (copper busbar)

40 mm x 10 mm; Max. 48 mm cable lug width at flange connection; Bolt diameter at flange connection: M10

Terminal capacity (copper strip)

16 mm x 0.8 mm (6x) - 32 mm x 1 mm (10x) at box terminal

Terminal capacity (stranded cable)

95 mm² - 300 mm² (1x) at box terminal; 120 mm² - 150 mm² (2x) at double clamp-type terminal; 25 mm² - 240 mm² at box terminal; 120 mm² - 240 mm² at clamp-type terminal

Connection type

Flat connection

Degree of protection

IP10 (handle cover open, XNH installed); IP20 (operating status, XNH installed); IP2XC (contact protection, XNH installed)

HS Code

8536.90

• EAN 4015081779925
• SAP 1200031843
• Code 81466189
