Eaton
MCB FAZ-B4/1-DC
Part numberFAZ-B4/1-DCEAN / GTIN4015081712618HS code8536.30
Electrical Components
Miniature Circuit Breakers
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Overview
Eaton MCB FAZ-B4/1-DC is listed under Electrical Components / Miniature Circuit Breakers. Sales unit: pcs; Package quantity: 12 pcs; Eaton catalogue number: 176065; Depth: 80 mm; Height: 75.5 mm; Width: 17.7 mm.
Technical Specifications
- Manufacturer part number (MPN)
- FAZ-B4/1-DC
- EAN / GTIN
- 4015081712618
- Sales unit
- pcs
- Package quantity
- 12 pcs
- Eaton catalogue number
- 176065
- Depth
- 80 mm
- Height
- 75.5 mm
- Width
- 17.7 mm
- Weight
- 0.112 kg
- Compliances
- RoHS conform
- Certifications
- EN45545-2; IEC 61373
- Current limiting class
- 3
- Features
- Additional equipment possible
- Special features
- Ambient temperature hint: a 1 °C increase results in a 0.5% linear reduction of current carrying capacity
- Used with
- Miniature circuit breaker; FAZ-DC
- Amperage Rating
- 4 A
- Application
- Switchgear for DC applications
- Number of poles
- Single-pole
- Number of poles (protected)
- 1
- Number of poles (total)
- 1
- Release characteristic
- B
- Tripping characteristic
- B
- Type
- FAZ-DC Miniature circuit breaker
- Ambient operating temperature - max
- 75 °C
- Ambient operating temperature - min
- -25 °C
- Equipment heat dissipation, current-dependent
- 1.4 W
- Rated operational current for specified heat dissipation (In)
- 4 A
- Overvoltage category
- III
- Pollution degree
- 2
- Rated impulse withstand voltage (Uimp)
- 4 kV
- Rated insulation voltage (Ui)
- 440 V
- Rated operational voltage (Ue) - max
- 250 V
- Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 230 V
- 10 kA
- Rated short-circuit breaking capacity (IEC 60947-2)- Icu at 400 V
- 10 kA
- Rated switching capacity (IEC/EN 60947-2)
- 10 kA
- Voltage type
- DC
- Built-in depth
- 70.5 mm
- Connectable conductor cross section (multi-wired) - max
- 25 mm²
- Connectable conductor cross section (multi-wired) - min
- 1 mm²
- Connectable conductor cross section (solid-core) - max
- 25 mm²
- Connectable conductor cross section (solid-core) - min
- 1 mm²
- Degree of protection
- IP20
- Width in number of modular spacings
- 1
- Document Name
- Description Action
- Power loss
- 1.4 W
- Number of protected poles
- 1
- Rated current
- 4 A
- Rated voltage
- 250 V
- Rated insulation voltage Ui
- 440 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Frequency
- 50–60 Hz
- Concurrently switching neutral conductor
- No
- Additional equipment possible
- Yes
- Ambient temperature during operating
- -25–75 °C
- Connectable conductor cross section multi-wired
- 1–25 mm²
- Connectable conductor cross section solid-core
- 1–25 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- Romania
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 4015081712618
- SAP 1200607002
- Code 82995931
