Selector Switch (T6-3-8212/E/HI12)

Eaton T6-3-8212/E/HI12 3-pole selector switch with 0-position. Recessed, front IP65.

Manufacturer part number (MPN)

T6-3-8212/E/HI12

EAN / GTIN

4015082147815

Sales unit

pcs

Eaton catalogue number

214781

Depth

88 mm

Height

200 mm

Width

88 mm

Weight

1.162 kg

Certifications

EN 60204; IEC 60947; EN 60947; VDE; IEC/EN 60947-3; IEC/EN 60947; VDE 0660; IEC/EN 60204

Catalog Notes

Rated Short-time Withstand Current (Icw) for a time of 1 second

Actuator function

With 0 (Off) position; Maintained

Actuator type

Short thumb-grip

Ambient operating temperature - max

50 °C

Ambient operating temperature - min

-25 °C

Ambient operating temperature (enclosed) - max

40 °C

Ambient operating temperature (enclosed) - min

-25 °C

Climatic proofing

Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclic, to IEC 60068-2-30

Control circuit reliability

1 failure per 100,000 switching operations statistically determined, at 24 V DC, 10 mA)

Number of auxiliary contacts (change-over contacts)

0

Number of auxiliary contacts (normally closed contacts)

0

Number of auxiliary contacts (normally open contacts)

0

Number of contacts

9

Heat dissipation per pole, current-dependent Pvid

11 W

Rated operational current for specified heat dissipation (In)

160 A

Rated breaking capacity at 220/230 V (cos phi to IEC 60947-3)

1280 A

Rated breaking capacity at 400/415 V (cos phi to IEC 60947-3)

900 A

Rated breaking capacity at 500 V (cos phi to IEC 60947-3)

880 A

Rated breaking capacity at 660/690 V (cos phi to IEC 60947-3)

340 A

Rated operational current (Ie)

75 A at AC-3, 230 V star-delta; 72.5 A at AC-3, 400 V star-delta; 34 A at AC-3, 690 V star-delta; 53 A at AC-3, 500 V star-delta

Rated operational current (Ie) at AC-21, 440 V

150 A

Rated operational current (Ie) at AC-23A, 230 V

126 A

Rated operational current (Ie) at AC-23A, 400 V, 415 V

138 A

Rated operational current (Ie) at AC-23A, 500 V

128 A

Rated operational current (Ie) at AC-23A, 690 V

60 A

Rated operational current (Ie) at AC-3, 220 V, 230 V, 240 V

75 A

Rated operational current (Ie) at AC-3, 380 V, 400 V, 415 V

72.5 A

Rated operational current (Ie) at AC-3, 500 V

53 A

Rated operational current (Ie) at AC-3, 660 V, 690 V

34 A

Rated operational current (Ie) at DC-13, control switches L/R = 50 ms

125 A

Rated operational current (Ie) at DC-23A, 120 V

50 A

Rated operational current (Ie) at DC-23A, 24 V

125 A

Rated operational current (Ie) at DC-23A, 48 V

125 A

Rated operational current (Ie) at DC-23A, 60 V

125 A

Rated operational power at AC-23A, 220/230 V, 50 Hz

37 kW

Rated operational power at AC-23A, 400 V, 50 Hz

75 kW

Rated operational power at AC-23A, 500 V, 50 Hz

90 kW

Rated operational power at AC-23A, 690 V, 50 Hz

55 kW

Rated operational power at AC-3, 380/400 V, 50 Hz

37 kW

Rated operational power at AC-3, 415 V, 50 Hz

37 kW

Rated operational power at AC-3, 690 V, 50 Hz

30 kW

Rated operational power star-delta at 220/230 V, 50 Hz

22 kW

Rated operational power star-delta at 380/400 V, 50 Hz

37 kW

Rated operational power star-delta at 500 V, 50 Hz

37 kW

Rated operational power star-delta at 690 V, 50 Hz

30 kW

Rated operational voltage (Ue) at AC - max

690 V

Rated uninterrupted current (Iu)

125 A

Uninterrupted current

Rated uninterrupted current Iu is specified for max. cross-section.

Enclosure material

Plastic

Fitted with

Black thumb grip and front plate; 0 (off) position

Inscription

1-0-2

Number of poles

3

Degree of protection

IP65

Degree of protection (front side)

IP65; NEMA 12

Lifespan, mechanical

100,000 Operations

Model

Reverser

Mounting method

Flush mounting

Mounting position

As required

Number of contact units

3

Operating frequency

50 Operations/h

Overvoltage category

III

Pollution degree

3

Product Category

Control switches

Rated impulse withstand voltage (Uimp)

6000 V AC

Safe isolation

440 V AC, Between the contacts, According to EN 61140

Safety parameter (EN ISO 13849-1)

B10d values as per EN ISO 13849-1, table C.1

Suitable for

Front mounting

Switching angle

60 °

Type

Changeover switch

Rated conditional short-circuit current (Iq)

5 kA

Rated short-time withstand current (Icw)

2 kA, Contacts, 1 second

Short-circuit protection rating

200 A gG/gL, Fuse, Contacts

Load rating

1.6 x Iₑ (with intermittent operation class 12, 40 % duty factor); 2 x Iₑ (with intermittent operation class 12, 25 % duty factor); 1.3 x Iₑ (with intermittent operation class 12, 60 % duty factor)

Number of contacts in series at DC-23A, 120 V

3

Number of contacts in series at DC-23A, 24 V

1

Number of contacts in series at DC-23A, 48 V

2

Number of contacts in series at DC-23A, 60 V

3

Rated making capacity up to 690 V (cos phi to IEC/EN 60947-3)

1600 A

Voltage per contact pair in series

42 V

Screw size

M6, Terminal screw

Terminal capacity (flexible with ferrule)

2 x 16 mm², ferrules to DIN 46228; 1 x 50 mm², ferrules to DIN 46228

Terminal capacity (solid/stranded)

2 x 25 mm²; 1 x 70 mm²

Tightening torque

39.8 lb-in, Screw terminals; 4.5 Nm, Screw terminals

Rated operation power at AC-3, 400 V

37 kW

Rated permanent current Iu

125 A

Rated operation current Ie at AC-3, 400 V

72.5 A

With zero (off) position

Yes

Housing material

Plastic

With retraction in 0-position

No

Degree of protection (IP), front side

IP65

Type of electrical connection of main circuit

Screw connection

Type of control element

Wing knob

Suitable for floor mounting

No

Suitable for front mounting

Yes

Suitable for distribution board installation

No

Suitable for intermediate mounting

No

Complete device in housing

No

Country of origin

Germany

HS Code

8536.50
