Dehn
Surge protection device Type 3 for TT/TN FM
Part number953205EAN / GTIN4013364108318HS code8536.30
Switchgear & Protection
Surge Protectors
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
Dehn 953205 Surge protection device Type 3 for TT/TN FM.
Technical Specifications
- Manufacturer part number (MPN)
- 953205
- EAN / GTIN
- 4013364108318
- Sales unit
- pcs
- Nominal voltage AC
- 230 V
- Max. continuous voltage AC
- 255 V
- Max. continuous voltage DC
- 255 V
- Nominal load current
- 25 A
- Nominal discharge surge current (8/20) (L-N)
- 3 kA
- Total discharge current (8/20) (L+N-PE)
- 3 kA
- Voltage protection level
- 1.5 kV
- Voltage protection level L-N
- 1.25 kV
- Voltage protection level L-PE/N-PE
- 1.5 kV
- Max. overcurrent protection device, series connection (fuse)
- 25 A
- Number of poles
- 2
- Mounting method
- DIN rail (top hat rail) 35 mm
- Max. conductor cross section solid (solid, stranded)
- 4 mm²
- Max. conductor cross section flexible (fine-strand)
- 2.5 mm²
- With remote signalling contact
- Yes
- Signalling at the device
- Optical
- Category type 3
- Yes
- With interference suppressor filter
- No
- Degree of protection (IP)
- IP20
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.30
Cross References
- EAN 4013364108318
- SAP 1000287766
- Code 843130
Product Documentation
Document preview: Surge protection device Type 3 for TT/TN FM (953205) — Specification sheet
