Product Description
Danfoss VRG 2 2-way seated throttling control-valve body (OEM designation "VRG2 PN16 DN15/1,6 ext.thread"). A external-thread globe-type valve body for motorised control of District heating/cooling circulation water on heating, cooling and district-heating circuits — driven by a separately-ordered Danfoss AMV/AME electric actuator for variable-flow throttling. Valve size DN 15; PN 16; Kvs 1.6 m³/h; 2 ports; External Thread connection G 1; Equal percentage flow characteristic; control ratio 50:1; body Grey cast iron EN-GJL-250 (GG-25); cone Brass; stem Stainless steel; stuffing-box seal EPDM; seat leakage bubble tight design % Kvs. Media District heating/cooling circulation water (Glycolic water up to 50%), -10 °C to 130 °C. OEM P/N 065Z0133. EAN 5702421559642. Technical data quoted verbatim from store.danfoss.com (code 065Z0133).
Technical Specifications
- Code number
- 065Z0133
- Type
- VRG 2
- Product group
- Other valves
- Gross weight
- 0.755 Kilogram
- Net weight
- 0.682 Kilogram
- Volume
- 1.496 Liter
- Application
- Heating and cooling
- Application alternative VSP
- District heating
- Cavitation factor
- 0.4
- Connection size
- G 1
- Connection types
- External Thread
- Control ratio
- 50:1
- Description
- VRG2 PN16 DN15/1,6 ext.thread
- Diameter [mm]
- 15 mm
- Differential pressure range [bar] [Max]
- 4 bar
- Flow characteristic
- Equal percentage
- Kvs values [m³/h]
- 1.6 m³/h
- Leakage through port (B-AB) max. [% Kvs]
- 1.0
- Leakage through port max. [% Kvs]
- bubble tight design
- Media pH [Max]
- 10
- Media pH [Min]
- 7
- Media temperature [°C] [Max]
- 130 °C
- Media temperature [°C] [Min]
- -10 °C
- Medium alternative
- Glycolic water up to 50%
- Mounting version
- Flow
- Number of ports
- 2
- Permissible media
- District heating/cooling circulation water
- PN alternative VSP
- 10
- Pressure nominal [bar]
- 16 bar
- Stroke [mm]
- 10 mm
- Stuffing box sealing material
- EPDM
- Valve body material
- Grey cast iron EN-GJL-250 (GG-25)
- Valve cone material
- Brass
- Valve stem material
- Stainless steel
- EAN
- 5702421559642
- HS code
- 8481.80
Standards & Compliance
- Size / Series
- VRG 2
- Material
- Grey cast iron EN-GJL-250 (GG-25)
- Thread Standard
- External Thread G 1
- Pressure Rating
- PN 16
- Temperature Range
- -10 °C to 130 °C
- HS Code
- 8481.80
Compatibility & Fitment
Order a Danfoss AMV/AME linear actuator (10 mm stroke) to drive this VRG 2 body — the body ships without actuator. Two-port throttling valve. Match DN (DN 15), Kvs (1.6), PN (PN 16) and the external-thread connection (G 1) against the VRG/VRB data sheet before ordering; external-thread and internal-thread bodies of the same DN are not interchangeable.
