Product Description
Danfoss VFGS 2 two-way flanged steam/stainless-bellows globe (seat) valve body, OEM order code 065B2764. Nominal size DN 250, pressure class PN 40, flow coefficient Kvs 630 m³/h. VFGS 2 is the stainless-steel-bellows globe valve body used with a matched self-acting (AFA/AFP/AFPB/AFQ/AFPQ/AFT) or motorised (AMV/AME) actuator for steam and district-heating service. Flanged connection Flange, seat diameter 250 mm. Data quoted verbatim from store.danfoss.com (code 065B2764). EAN 5710104506920. HS 8481.80.
Technical Specifications
- Brand
- Danfoss
- Part number
- 065B2764
- Code number
- 065B2764
- Number of ports
- 2
- Type
- VFGS 2
- Product group
- Pressure flow controllers
- Description
- VFG(S)2 PN40 250/630 2-way flange fl/ret
- Valve size
- DN 250
- Diameter [mm]
- 250 mm
- Kvs values [m³/h]
- 630 m³/h
- Connection types
- Flange
- Pressure class
- PN 40
- Contains batteries
- No
- REACH Candidate List substances
- No
- Net weight
- 396 Kilogram
- Gross weight
- 449.5 Kilogram
- Volume
- 1274.643 Liter
- EAN
- 5710104506920
- HS code
- 8481.80
- China RoHS compliance
- Out of scope
- EU RoHS compliance
- Out of scope
Standards & Compliance
- Size / Series
- DN 250
- Pressure Rating
- PN 40 (40 bar)
- HS Code
- 8481.80
Compatibility & Fitment
Valve body for Danfoss self-acting / motorised control assemblies. Combine the VFGS 2 DN 250 body with a matched actuator sized for the required duty. Select the body by nominal size (DN 250), pressure class (PN 40) and flow coefficient (Kvs 630 m³/h) before ordering — VFGS 2 bodies are not interchangeable across DN/PN.
