Danfoss SAVA safety pressure-relief controller, PN 25, DN 40, kVS 16 m³/h, setting 2 – 7.5 bar, external thread G 2 A, bypass mounting

Danfoss SAVA (003H6964) — self-acting safety pressure-relief controller, PN 25, DN 40, bypass mounting, for district heating and central-heating circuits. The SAVA is a self-acting safety pressure-relief controller that requires no auxiliary energy: it opens on rising pressure to relieve the circuit, using a control valve and a spring-loaded actuator diaphragm. As a safety controller (SÜV pressure-relief) it provides the self-acting overpressure protection required for district-heating substations, independent of any electric control. kVS 16 m³/h; adjustable pressure setting range 2 – 7.5 bar; maximum differential pressure 16 bar. Medium temperature 2–150 °C; leakage 0.05% of kVS (IEC 534); Valve body ductile iron EN-GJS-400-18-LT (GGG 40.3), valve seat stainless steel 1.4571, valve cone dezincing free brass CuZn36Pb2As, actuator diaphragm EPDM. Connection external thread G 2 A (ISO 228/1). OEM P/N 003H6964, EAN 5710104031132. Technical data quoted verbatim from store.danfoss.com (code 003H6964).

Code number

003H6964

Type

SAVA

Function

Safety press. relief controller (SÜV)

Product group

Pressure and flow controllers

Description

Self-acting safety pressure-relief controller (district heating), adjustable setting, bypass mounting

Valve size

DN 40

Pressure class

PN 25

kVS value

16 m³/h

Connection

external thread G 2 A (ISO 228/1)

Pressure setting range

2 – 7.5 bar (adjustable)

Max. differential pressure

16 bar

Application

District Heating

Medium

District heating/cooling circulation water / glycolic water up to 30% (pH 7–10)

Medium temperature

2 – 150 °C

Leakage (IEC 534)

0.05% of kVS

Mounting version

Bypass

Stem position

Normally closed

Valve body

Ductile iron EN-GJS-400-18-LT (GGG 40.3)

Valve seat

Stainless steel, mat. No. 1.4571

Valve cone

Dezincing free brass CuZn36Pb2As

Actuator diaphragm

EPDM

EU RoHS compliance

Yes with exemptions (6(c))

REACH Candidate List substance

Lead (CAS no. 7439-92-1)

Net weight

9.473 Kilogram

Gross weight

9.886 Kilogram

Packed volume

31.862 Liter

EAN

5710104031132

HS code

8481.80

Material

Valve body ductile iron EN-GJS-400-18-LT (GGG 40.3); valve seat stainless steel 1.4571; valve cone dezincing free brass CuZn36Pb2As; actuator diaphragm EPDM

Thread Standard

ISO 228/1

Pressure Rating

PN 25 (max. differential pressure 16 bar)

Temperature Range

2 – 150 °C (medium)

HS Code

8481.80
