Danfoss valve insert, PN 25, for VG, DN 20, Kvs 6.3 m³/h, globe-valve spare

Danfoss valve insert (003H6874) — genuine PN 25 spare cone + seat cartridge for the Danfoss VG globe-valve range. The insert is the replaceable throttling element (cone and seat) that drops into the valve body; renewing it restores the original flow characteristic and Kvs without changing the body. Valve size DN 20. Kvs 6.3 m³/h. Pressure class PN 25 for district heating/cooling circulation water. Fits Danfoss VG valves/controllers. OEM designation "Valve insert PN25 20/6,3 25/6,3 VG-flow". Net weight 0.206 kg, gross 1.053 kg. Contains lead per the REACH candidate list. OEM P/N 003H6874. EAN 5702421553367. Technical data quoted verbatim from store.danfoss.com (code 003H6874).

Code number

003H6874

Type

Valve Inserts

Product group

Accessories — SAC (self-acting controllers)

For product type

VG

Valve size

DN 20

Kvs value

6.3 m³/h

Function

Replaceable cone + seat insert cartridge for the globe-valve body

Pressure class

PN 25

Permissible media

District heating/cooling circulation water

OEM description

Valve insert PN25 20/6,3 25/6,3 VG-flow

REACH Candidate List substance

Lead (CAS no. 7439-92-1)

Volume

0.568 L

Net weight

0.206 kg

Gross weight

1.053 kg

EAN

5702421553367

HS code

8481.90

Description

Valve insert PN25 20/6,3 25/6,3 VG-flow

Kvs values [m³/h]

6.3 m³/h

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

Pressure Rating

PN 25

HS Code

8481.90
