Danfoss QT 45-60°C, DN15-32 (4.0), thermostatic actuator for return temperature control
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss QT self-acting thermostatic actuator for return-temperature control on Danfoss one-pipe / AB-QM installations. QT 45-60°C, DN15-32 (4.0), thermostatic actuator for return temperature control. Temperature setting range 45 °C to 60 °C. For AB-QM size DN 15-32. Capillary tube length 0.6 m. Part of the Danfoss One-pipe solutions range. OEM P/N 003Z0398. EAN 5714279227680. Technical data quoted verbatim from store.danfoss.com (code 003Z0398).
Technical Specifications
- Code number
- 003Z0398
- Type
- QT
- Product group
- One-pipe solutions
- Capillary tube length [m]
- 0.6 m
- China RoHS compliance
- Out of scope
- Compatibility with AB-QM size
- DN 15-32
- Contains batteries
- No
- Description
- QT 45-60°C, DN15-32 (4.0), thermostatic actuator for return temperature control
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- RoHS Compliant
- Out of scope
- SCIP dossier no.
- ce259842-5928-46a5-b912-7710c1887d5a
- SCIP dossier product name
- QT
- Temperature setting range [°C] [Max]
- 60 °C
- Temperature setting range [°C] [Min]
- 45 °C
- Gross weight
- 0.23 Kilogram
- Net weight
- 0.214 Kilogram
- Volume
- 1.441 Liter
- EAN
- 5714279227680
Standards & Compliance
- Temperature Range
- 45 °C to 60 °C (setting range)
- HS Code
- 9032.10
Compatibility & Fitment
Danfoss one-pipe / AB-QM return-temperature control component. Confirm AB-QM size compatibility and setting range against the system design before ordering.
