Danfoss PM inspection / service kit for PMFL / PMFH / PM size 50 main valves

Danfoss inspection / service kit, code 027F3078, for the pilot-operated PM servo main valves type PMFL, PMFH, PM, PML, PMLX and MRV in size 50. The kit contains the valve cone and sealing parts required to inspect and overhaul the main valve, and covers both cone types used in that size. Supplied multi pack (8 pc). PM main valves are the servo (pilot-operated) main valves of a Danfoss liquid-level or pressure-regulating station; this kit renews the wear parts without replacing the valve body. Match the kit to the main-valve size (50). Spare part / accessory — price on quote (login-gated on the Danfoss store).

Type

Inspection kit (service kit)

Code number

027F3078

Product group

Spare parts and accessories for Valves

Function

Overhaul / inspection kit — cone and sealing set for the PM servo-operated main valve

Used for products

PM 3-50; PM, PML, PMLX, MRV size 50

Covers valve size(s)

50

Cone types covered

Both cone types

Packing format

Multi pack (8 pc)

Net weight

0.086 kg

Gross weight

0.094 kg

Volume

0.333 liter

EU RoHS compliance

Yes

China RoHS compliance

Yes

EAN

5702428470193

Compatible with

PMFL / PMFH / PM size 50 main valves

REACH Candidate List substances

No

Type designation

Inspection kit

Used for product

PM 3-50

Used for product comments

Both cone types

Material

Steel / elastomer seals

HS Code

8481.90
