Danfoss LENO MSV-B DN 15 Low Flow External Thread manual balancing valve

Danfoss LENO MSV-B — manual (static) double-regulating balancing valve, OEM order code 003Z4130. Manual static double-regulating balancing valve with presetting and integral shut-off for constant-flow hydronic balancing of heating and cooling systems. The digital handwheel presets the branch/riser hydraulic resistance to fix the design flow; the valve also functions as a shut-off with a drain facility. (MSV-B DN 15 Low flow, External thread, manual balancing valve.) Nominal size DN 15, Kvs 2.5 m³/h, PN 20, External Thread connection (G ¾ A), DZR brass body, media temperature -20 °C to 120 °C. Net weight 0.671 Kilogram. Genuine Danfoss part; technical data quoted verbatim from store.danfoss.com (code 003Z4130). OEM P/N 003Z4130, EAN 5702420096339. Used in commercial refrigeration, provision-room cooling and reefer plant rooms across HFC, HFO and CO2 (R744) refrigerants.

Brand

Danfoss

Part number

003Z4130

Type

LENO MSV-B

Product group

Manual balancing

Function

manual (static) double-regulating balancing valve

Store description

MSV-B DN 15 Low flow, External thread, manual balancing valve

Nominal size

DN 15 (Low Flow variant)

Kvs value

2.5 m³/h

Connection thread size

G ¾ A

Connection type

External Thread

Pressure class

PN 20

Setting scale

Yes

Test plugs

With test plugs

Shut-off function

Yes

Drain function

No

Valve body material

DZR brass

Media temperature

-20 °C to 120 °C

REACH candidate-list substances

Lead (CAS no. 7439-92-1)

Net weight

0.671 Kilogram

Gross weight

0.73 Kilogram

EAN

5702420096339

HS code

8481.80 (taps, cocks, valves for pipes, tanks, vats or the like)

Material

Valve body DZR brass

Pressure Rating

PN 20

Temperature Range

-20 °C to 120 °C (media)

Classification / Approval

CE

HS Code

8481.80
