Danfoss ICS1 25-25 pilot-operated servo valve, 28 mm (1 1/8 in) solder (ASME B 16.22), steel, Kv 11.5 m³/h (code 027H2066)
Danfoss · HVAC & Refrigeration · Expansion Valves
Danfoss ICS1 25-25 pilot-operated servo main valve (code 027H2066) for industrial refrigeration. Straightway steel body with soldering connections both ends, 28 mm (1 1/8 in), to ASME B 16.22; flow coefficient Kv 11.5 m³/h (Cv 13 gal/min). The ICS 1 main valve carries a single pilot function module on its top cover, setting one control function (constant pressure, solenoid on/off, differential-pressure or other pilot, ordered separately). Maximum working pressure 65 bar (943 psig); media temperature -60 to +120 °C (-76 to 248 °F). Suitable for R717 (ammonia), R744 (CO₂), HFC and hydrocarbon refrigerants and their oils. Specifications per Danfoss store code 027H2066.
Specifications
- Part number
- 027H2066
- HS code
- 8481.80
- Material
- Steel
- Pressure rating
- 65 bar
- Temperature range
- -60 to +120 °C
- Standard
- ASME B 16.22
- Standard size
- 25 mm (1 in)
Compatibility
Danfoss ICS 1 single-pilot servo main valve for industrial refrigeration. Function is set by the pilot module(s) fitted to the top cover. Select by Kv/cone (ICS1 25-25) and connection (Soldering ASME B 16.22); the butt-weld, socket-weld and solder variants of the same cone are separate codes. Verify Kv, pilot configuration and refrigerant compatibility against your duty before ordering.
