Danfoss HPBV high-pressure by-pass valve, 32 mm, PN 16, setting range 0.5 – 2.5 bar

Danfoss HPBV (003H6006) — self-acting high-pressure by-pass valve, 32 mm, PN 16, for heating and district-heating circuits. The HPBV is a self-acting differential-pressure relief (by-pass) valve. It stays closed until the differential pressure across it exceeds the spring setting, then opens to bypass excess flow — protecting the circuit and maintaining a minimum flow through the pump when consumer valves close. Adjustable opening (differential) pressure 0.5 – 2.5 bar. OEM P/N 003H6006, EAN 5702428567237. Technical data quoted verbatim from store.danfoss.com (code 003H6006).

Code number

003H6006 Type: HPBV Product group: Pressure and flow controllers Description: Self-acting high-pressure by-pass (differential-pressure relief) valve Nominal diameter: 32 mm Nominal pressure: PN 16 Pressure setting range: 0.5 – 2.5 bar EU RoHS compliance: Yes with exemptions (6(c)) REACH Candidate List substance: Lead (CAS no. 7439-92-1) SCIP dossier no.: 96ca0d96-053f-402a-aeb3-e881573a74ac Net weight: 0.942 Kilogram Gross weight: 0.944 Kilogram Packed volume: 1.119 Liter EAN: 5702428567237 HS code: 8481.40 China RoHS compliance: Yes with exemptions China RoHS exemption clause: 7.3 Diameter [mm]: 32 mm EU RoHS exemption clause: 6(c) Pressure nominal [bar]: 16 bar Pressure setting range [bar] [Max]: 2.5 bar Pressure setting range [bar] [Min]: 0.5 bar REACH Candidate List substances: Lead (CAS no. 7439-92-1)

Pressure Rating

PN 16 (opening pressure 0.5 – 2.5 bar)

HS Code

8481.40
