Danfoss VLT Automation Drive FC-301 — 7,5 kW, 200-240 VAC, IP55
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss VLT Automation Drive FC-301 — 7,5 kW, 200-240 VAC, IP55. Reference part number 131B9912.
Technical Specifications
- Type code
- FC-102P7K5T2P55H2XGX1XXSXXXXAXBXCXXXXDX
- Code number
- 131B9912
- Rated shaft output
- 7,5 kW
- Supply voltage
- 200–240 V AC
- Enclosure rating
- IP55
- Series
- VLT Automation Drive FC-301
- Power rating
- 7.5 kW
- IP rating
- IP55
- Product Group
- FC-
- Phase
- T
- Mains Voltage
- 2
- Enclosure
- P55
- RFI Filter
- H2
- Brake - Safe Stop
- X
- LCP
- G
- Coating PCB
- X
- Mains Option
- 1
- Adaptation A
- X
- Adaptation B
- X
- Software Release
- SXXX
- Software Language Pack
- X
- A Option
- AX
- B Option
- BX
- C0 Option MCO
- CX
- C1 Option
- X
- C Option Software
- XX
- D Option
- DX
- Frame Size
- B1
- Height [mm]
- 494,0
- Width w/ no C options [mm]
- 243,0
- Depth [mm]
- 261,0
- Depth with Option A/B [mm]
- 261,0
- Product Catalog
- NO_VIEW
- Power 110% (NO) [KW]
- 7.5
- kVA
- 11.1
- Power Loss NO [W]
- 310
- Continuous Current (NO) [A]
- 30.8
- Intermittent Current (NO) [A]
- 33.9
- ECCN EU
- Y901
- ECCN US
- 3A999.a
- Product View (Switch)
- GLBL
Standards & Compliance
- HS Code
- 8504.40
Product Documentation
