Danfoss Pipe Heat Exchanger - HE 1.0, 3/8", 5/8"
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss Pipe Heat Exchanger. Receivers and suction accumulators (Refrigeration technology / Cooling technical components). Principal data: type designation HE 1.0, connection 1 3/8", connection 2 5/8". Supplied under manufacturer part number 015D0004, HS code 8419.50, country of origin Poland.
Technical Specifications
- Product type
- Receivers and suction accumulators
- Product group
- Cooling technical components
- Type designation
- HE 1.0
- Connection 1
- 3/8"
- Connection 2
- 5/8"
- Sales unit
- Pack
- Carbon footprint (EPD)
- 3.1293 kg CO2e per pcs
- Country of origin
- Poland
- Customs tariff code (EU CN)
- 84195080
- HS code
- 8419.50
- Manufacturer part number
- 015D0004
- EAN
- 5702422006053
- Net weight
- 0.52 Kilogram
- Type
- HE 1.0
- Approval
- EAC
- China RoHS compliance
- Yes
- Connection Code
- (3002:X:16; 3002:X:10)
- Customer part number
- 00A134
- EU RoHS compliance
- Out of scope
- Inlet connection type
- Solder, ODF
- Inlet size [in]
- 5/8 in
- Lubricants compatibility
- Oilfree applications
- Max. test pressure [bar]
- 52 bar
- Max. test pressure [psig]
- 754 psig
- Max. Working Pressure [bar]
- 35 bar
- Max. Working Pressure [psig]
- 507 psig
- Medium temperature range [°C] [max]
- 120 °C
- Medium temperature range [°C] [min]
- -60 °C
- Medium temperature range [°F] [max]
- 248 °F
- Medium temperature range [°F] [min]
- -76 °F
- Oil free refrigerants
- R513A
- Outlet connection type
- Solder, ODF
- Outlet size [in]
- 3/8 in
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Refrigerants
- R1270
Standards & Compliance
- HS Code
- 8419.50
Cross References
- MPN 015D0004
Product Documentation
More from Danfoss
Danfoss
Danfoss MBS 3250 Pressure Transmitter - 1/4", 0-6bar
060G1863
Danfoss
Danfoss MBT 5250 Sensor - 1/2", 200mm
10248053
Danfoss
Danfoss MBS 3200 Pressure Transmitter - 1/2", 0-16bar
060G1876
Danfoss
Danfoss T 2 Thermostatic expansion valve flare/solder - R452A, External, -40-10°C, TE 2 R452A
