Danfoss Gear Motor - 10239962
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss Gear Motor. Engines/thermal engines (Plumbing / Heat / Valves for heating and cooling systems). Supplied under manufacturer part number 082G1451, EAN 5702421507599, HS code 8481.90, country of origin Denmark.
Technical Specifications
- Product type
- Engines/thermal engines
- Product group
- Heat
- REACH SVHC substance above 0.1%
- Lead
- Carbon footprint (EPD)
- 63.2306 kg CO2e per pcs
- Country of origin
- Denmark
- Customs tariff code (EU CN)
- 84819000
- HS code
- 8481.90
- Manufacturer part number
- 082G1451
- VVS number
- 461072551
- EAN
- 5702421507599
- Net weight
- 9.733 Kilogram
- Type
- AMV 85
- Actuator speed [s/mm]
- 8 s/mm
- Actuator type
- Electrical
- Ambient temperature [°C] [max]
- 55 °C
- Ambient temperature [°C] [min]
- 0 °C
- Application
- HD HVAC and DH
- China RoHS compliance
- Out of scope
- Closing force [N]
- 5000 N
- Control signal type
- 3-point
- Description
- AMV 85 230V 8s/mm 40mm 5000N
- EU RoHS compliance
- Yes with exemptions
- EU RoHS exemption clause
- 6(c)
- Frequency [Hz]
- 50/60
- Grade of enclosure
- IP54
- Manual operation
- Yes
- Position feedback
- no - potentiometer needed
- Power consumption [W]
- 11 W
- Protection Class of the Coating
- II
- REACH Candidate Strip substances
- Lead (CAS no. 7439-92-1)
- Safety function
- No
- Speed type
- Standard
- Spring down (return)
- No
- Spring up
- No
- Storage temperature [°C] [Max]
- 70 °C
- Storage temperature [°C] [Min]
- -40 °C
- Stroke [mm]
- 40 mm
- Supply voltage [V]
- 230 V AC
- Turn time per 90° [s]
- 0 "
Standards & Compliance
- HS Code
- 8481.90
Cross References
- MPN 082G1451
- EAN 5702421507599
- VVS 461072551
Product Documentation
