Danfoss AF-range seal pot V3 — 3 L condensate/seal pot for self-acting controller actuators
Pricing
Request a quote
We reply within 24 hours
Product Description
Danfoss AF-range seal pot V3 (OEM designation "Seal pot V3, 3.0 l, AF range"), filling volume 3 L. The seal pot forms a water-filled buffer between hot process medium and the self-acting AF-range controller actuator, keeping the actuator diaphragm within its permitted temperature on high-temperature (e.g. steam or high-temperature water) applications. Ordered separately and plumbed into the impulse line between the pressure tapping and the actuator. This is the heavy-duty V3 size (3 L). OEM P/N 003G1403. EAN 5702421813461. Technical data quoted verbatim from store.danfoss.com (code 003G1403).
Technical Specifications
- Code number
- 003G1403
- Type
- Seal pots
- Product group
- Accessories - SAC
- Gross weight
- 6.5 Kilogram
- Net weight
- 6.5 Kilogram
- Volume
- 7.4 Liter
- Contains batteries
- No
- Description
- Seal pot V3, 3.0 l, AF range
- Filling volume [l]
- 3 L
- REACH Candidate List substances
- Lead (CAS no. 7439-92-1)
- SCIP dossier no.
- 93a24a3c-a530-454a-8fb3-87a807b62693
- SCIP dossier product name
- SAC HD SEAL POT
- EAN
- 5702421813461
- HS code
- 8481.90
Standards & Compliance
- Size / Series
- Seal pots
- HS Code
- 8481.90
Compatibility & Fitment
The seal pot V3 mounts in the impulse line ahead of a Danfoss AF-range self-acting controller actuator to protect the diaphragm from high media temperature. Filling volume 3 L. Confirm the required seal-pot size against the AF-range data sheet for the media temperature of the application.
