Danfoss AB-QM ANSI ¾" high-flow pressure-independent balancing & control valve, NPT, without test plugs

Danfoss AB-QM ANSI ¾" — high-flow pressure-independent balancing and control valve (PICV) with external NPT thread for North-American terminal-unit piping. A built-in differential-pressure controller keeps the flow through the settable orifice constant regardless of pressure fluctuations elsewhere in the network, so each terminal delivers its design flow without manual re-balancing; the presetting dial fixes the maximum flow and the valve also acts as a shut-off. CW 617N body, External thread NPT connection, maximum flow 7.5 gal/min, control differential pressure 5 psi to 60 psi, static pressure to 300 psi, media temperature 15 °F to 250 °F. Supplied without test plugs. Actuator connection M30 x 1.5. OEM P/N 003Z1333. EAN 5710104061542. Technical data quoted verbatim from store.danfoss.com (code 003Z1333).

Code number

003Z1333

Type

AB-QM ANSI

Product group

Pressure independent balancing and control valves

Description

AB-QM ¾", High flow, without test plugs, pressure independent balancing and control valve

Valve size

¾" High flow

Valve body material

CW 617N

Connection types

External thread NPT

Actuator connection

M30 x 1.5

Test plugs

Without test plugs

Flow nominal [m³/h]

0 m³/h

Flow [gpm] [Max]

7.5 gal/min

Stroke [mm]

4 mm

Static pressure [psi] [Max]

300 psi

Differential pressure range [psi] [Min]

5 psi

Differential pressure range [psi] [Max]

60 psi

Media temperature [°F] [Min]

15 °F

Media temperature [°F] [Max]

250 °F

Contains batteries

No

EU RoHS compliance

Yes with exemptions

EU RoHS exemption clause

6(c)

China RoHS compliance

Out of scope

REACH Candidate List substances

Lead (CAS no. 7439-92-1)

SCIP dossier no.

c9bea54f-4bdf-47e5-8f19-a71801a13e6b

SCIP dossier product name

AB-QM 3/4" HF without test plugs

Net weight

0.711 Kilogram

Gross weight

0.711 Kilogram

Volume

1.298 Liter

EAN

5710104061542

Material

Valve body CW 617N

Pressure Rating

Static pressure 300 psi

Temperature Range

15 °F to 250 °F (media)

Classification / Approval

CE

HS Code

8481.80
