Danfoss JIP-II ball valve DN 20 PN 40 — reduced bore (065N2210)

Danfoss JIP-II industrial ball valve, DN 20 PN 40, reduced bore, internal thread × internal thread (Rp, ISO 7/1) connection. Two-port on/off isolation valve for Heating and cooling circulation water; weldable-steel body with stainless-steel ball and stem. Kvs 15 m³/h. Rated PN 40, media temperature 0 °C to 180 °C. OEM P/N 065N2210. EAN 5702421656242. Verbatim technical data from store.danfoss.com (code 065N2210).

Code number

065N2210

Type

JIP-II

Description

JIP-II DN 20 PN40 lo spec.

Product group

Ball valves

Function

On/off

Number of ports

2

Valve size

DN 20

Pressure class

PN 40

Valve type

Reduced Bore

Connection types

Internal thread

Rotation angle

90 °

Kvs values (m³/h)

15 m³/h

Leakage rate

Leakage rate A

Differential pressure range (max)

40 bar

Media temperature (min)

0 °C

Media temperature (max)

180 °C

Permissible media

District heating/cooling circulation water

Ambient temperature (min)

-40 °C

Storage temperature (min)

-40 °C

Mounting orientation

All

EU RoHS compliance

Out of scope

China RoHS compliance

Out of scope

REACH Candidate List substances

No

Net weight

0.719 kg

Gross weight

0.719 kg

EAN

5702421656242

Material

Body: weldable steel #20 (CE/PED-approved); ball & stem: stainless steel

Pressure Rating

PN40

Temperature Range

0 °C to 180 °C (media)

Classification / Approval

CE / PED

HS Code

8481.80
