Meter Wireless MBUS EXT ANT (EM24DINAV53XW1EX)

Carlo Gavazzi EM24DINAV53XW1EX Manufacturer description: Three-phase Energy analyzer, 120 to 277 V L-N, 208 to 480 V L-L, 5 (10) A, Wireless M-Bus, external antenna. Energy meter EM24DINAV53XW1EX.

Manufacturer part number (MPN)

EM24DINAV53XW1EX

EAN / GTIN

8030956087376

Sales unit

pcs

Voltage inputs

3-phase (4-wire), 230/400 V; 3-phase (3-wire), 400 V L-L

Frequency

50Hz; 60Hz

Current inputs

5 A current transformers

Energy metering

Consumption and generation

Communication port and protocol

wireless M-Bus with external antenna

Power supply

Self power supply

Approvals, marks, declarations

CE (Europe); UKCA (UK)

E-number (NO)

8200750

E-number (SE)

0902429

Mounting method

DRA (DIN-rail adaptor)

Model

Measurement transformer

Suitable for

Purchase/supply

Max. current (Imax)

10 A

Width in number of modular spacings

4

Number of positions total (counter)

8

Type of meter

Electronic

Degree of protection (IP)

IP50

Type of interface

M-bus (wired)

Energy type

Effective power and reactive power

Calibrated

Yes

Pulse output

Optical

Accuracy class

B

Pole type

Three conductor/four conductor

With lock code

Yes

Nominal voltage (Un) N-L

120–277 V

Nominal voltage (Un) L-L

208–480 V

Nominal current (In)

5 A

Country of origin

China

HS Code

9031.80

• EAN 8030956087376
• SAP 1200453783
• Code 82514718
