KWh meter 3-Phase 230/400VAC (EM21072DMV53XOSX)
Pricing
Request a quote
We reply within 24 hours
Product Description
Carlo Gavazzi EM21072DMV53XOSX Manufacturer description: Three-phase Energy analyzer, 160 to 240 V L-N, 277 to 415 V L-L, 333 mV (400 mV) A, RS485 Modbus RTU Pulse output. EM21072DMV53XOSX ENERGIMETER.
Technical Specifications
- Manufacturer part number (MPN)
- EM21072DMV53XOSX
- EAN / GTIN
- 8030956079579
- Sales unit
- pcs
- Voltage inputs
- 1-phase (2-wire), 220 V L-N; 1-phase (2-wire), 230 V L-N; 1-phase (2-wire), 240 V L-N; 3-phase (4-wire), 220/380 V; 3-phase (4-wire), 230/400 V; 3-phase ( 4-wire), 240/415 V; 3-phase (3-wire), 380 V L-L; 3-phase (3-wire), 400 V L-L; 3-phase (3-wire), 415 V L-L
- Frequency
- 50Hz; 60Hz
- Current inputs
- 333 mV current sensors; Rogowski coils
- Energy metering
- Consumption and generation
- Communication port and protocol
- RS485 (Modbus RTU)
- Power supply
- Self power supply
- Approvals, marks, declarations
- CE (Europe); UKCA (UK)
- E-number (NO)
- 8200407
- E-number (SE)
- 0921001
- Mounting method
- DRA (DIN-rail adaptor)
- Width
- 72 mm
- Model
- Direct measurement
- Height
- 72 mm
- Depth
- 58 mm
- Suitable for
- Purchase/supply
- Type of indication
- Digital
- Width in number of modular spacings
- 4
- Number of positions total (counter)
- 7
- Type of meter
- Electronic
- Degree of protection (IP)
- IP40
- Type of interface
- Modbus
- Energy type
- Effective power and reactive power
- Calibrated
- Yes
- Approval
- Domestic
- Pulse output
- Electrical
- Pulse rate
- 0.1–100 Imp/kWh (kvarh)
- Accuracy class
- B
- Pole type
- Three conductor
- Measurement type load profile
- No
- EEC40 signature
- No
- With lock code
- Yes
- Nominal voltage (Un) N-L
- 160–240 V
- Nominal voltage (Un) L-L
- 277–415 V
- Nominal current (In)
- 5 A
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 9030.90
Cross References
- EAN 8030956079579
- SAP 1200081351
- Code 81971308
Product Documentation
