3-phase network monitoring relay, overvoltage/undervoltage 208-240 V

Mains monitoring relay, 3-phase AC. Manufacturer description: 3-phase monitoring relay for phase loss, over- or undervoltage, nominal range 380-480 V AC, delay on alarm 0.1-30 s, SPDT relay output, regenerated voltage detection, 22.5 mm DIN-rail housing. Overvoltage/undervoltage + phase loss. For DIN-rail.

Manufacturer part number (MPN)

DPB01CM23N

EAN / GTIN

8030956034622

Sales unit

pcs

Mounting

Industrial DIN-rail

Function

Phase loss; Overvoltage; Undervoltage

3-phase voltage range

208-240 Vac

Frequency range

50-60 Hz

Output

1 relay

Time delay

Delay on alarm

Approvals, marks, declarations

for Europe; for North America; for China; for Australia

Setting method through NFC

No

E-number (NO)

4360113

Rated switch current

8 A

Voltage type (operating voltage)

AC

Type of electric connection

Screw connection

Rated control supply voltage AC 50 Hz

208–240 V

Rated control supply voltage AC 60 Hz

208–240 V

Voltage type for actuating

AC

Min. adjustable delay-on energization time

0 s

Min. adjustable off-delay time

0.1 s

Max. permitted off-delay time

30 s

Number of contacts as normally closed contact

1

Number of contacts as normally open contact

1

Number of contacts as change-over contact

1

Width

22.5 mm

Height

83.5 mm

Depth

99.5 mm

Country of origin

Italy

HS Code

9030.90
