FOTO.Pole.Flat,DC,NO+NC,Plug (PC50CNP06BAM1)
Pricing
Request a quote
We reply within 24 hours
Product Description
Carlo Gavazzi PC50CNP06BAM1 Manufacturer description: Polarized Retro-reflective Photoelectric Sensor, Range 6000mm, red polarized modulated light 660nm, Power Supply 10-30VDC, NPN Output, NO and NC, Light and Dark Switching, M12 Plug. PC50CNP06BAM1 Photocells with accessories.
Technical Specifications
- Manufacturer part number (MPN)
- PC50CNP06BAM1
- EAN / GTIN
- 5709870268347
- Sales unit
- pcs
- Output type
- PNP/NPN
- Output function
- Complementary (NO+NC)
- Connection Type
- Connector M12
- Housing style
- Rectangular
- Housing Material
- Plastic
- Type of light
- Polarized red light
- Sensing mode
- Light-/dark switching
- Degree of protection
- IP67
- Rated Operetional voltage UB at DC
- 10 V ... 30 V
- E-number (NO)
- 4351119
- Rated switching distance
- 6000 mm
- Max. switching distance
- 6000 mm
- Max. output current
- 200 mA
- With reflector
- No
- Setting procedure
- Manual adjustment
- Number of semiconductor outputs with signalling function
- 2
- Number of protected semiconductor outputs
- 2
- Type of electric connection
- Cable
- Type of switching output
- NPN/NPN
- Type of switch function
- Anticoincidence
- Operation agent-safety class
- Safety class 0
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cuboid
- Width sensor
- 17 mm
- Height of sensor
- 50 mm
- Length of sensor
- 50 mm
- Material of optical surface
- Plastic
- Max. output current at protected output
- 200 mA
- Min. reflector distance
- 200 mm
- Response time
- 1 ms
- Switching frequency
- 500 Hz
- Type of safety according to IEC 61496-1
- 1
- Switching voltage of OSSD at state "high"
- 30 V
- Voltage type
- DC
- Laser protection class
- None
- Wavelength of the sensor
- 660 nm
- Light dot
- 34500 mm²
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 9030.90
Cross References
- EAN 5709870268347
- SAP 1200454297
- Code 82529111
Product Documentation
More from Carlo Gavazzi
Carlo Gavazzi
Motor Load Monitor cos. phi 208-240V (PWB02CM2310A)
Carlo Gavazzi
Carlo Gavazzi ZRLS12GA Slim relay socket for RSLM slim relays, 5-pin, 12/24 V AC/DC coil, push-in spring terminals
Carlo Gavazzi
Meter Wireless MBUS INT ANT (EM24DINAV23XW1IPFA)
Carlo Gavazzi
Meter Wireless MBUS EXT ANT (EM24DINAV53XW1EPFB)
Carlo Gavazzi
Inductive Transmitter ICB18S30F05PO
Carlo Gavazzi
Auxiliary Relay 11-Pin 110VDC
RCP11003110VDC
Carlo Gavazzi
IND Transmitter M30 NPN NC Shielded 2M Cable
ICS30L50F15NCB2E1
Carlo Gavazzi
Wireless receiver for LORA
UWPMM1UL1X
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy PC50CNP06BAM1?
- PC50CNP06BAM1 can be ordered from cballast.com as a Carlo Gavazzi catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Carlo Gavazzi product?
- The manufacturer part number is PC50CNP06BAM1.
- What is the HS code for PC50CNP06BAM1?
- The customs tariff (HS) code for PC50CNP06BAM1 is 9030.90.
- Who manufactures PC50CNP06BAM1?
- PC50CNP06BAM1 is a Carlo Gavazzi product in the Sensors & Instrumentation range.
- Is a datasheet available for PC50CNP06BAM1?
- Yes — the PC50CNP06BAM1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for PC50CNP06BAM1?
- The minimum order quantity is 1.
- Is PC50CNP06BAM1 available?
- Yes — PC50CNP06BAM1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
