Meter Wireless MBUS INT ANT (EM24DINAV23XW1IPFA)
Pricing
Request a quote
We reply within 24 hours
Product Description
Carlo Gavazzi EM24DINAV23XW1IPFA Manufacturer description: Three-phase MID Energy analyzer, 133 to 230 V L-N, 230 to 400 V L-L, 10 (65) A, Wireless M-Bus, internal antenna. Energy meter EM24DINAV23XW1IPFA.
Technical Specifications
- Manufacturer part number (MPN)
- EM24DINAV23XW1IPFA
- EAN / GTIN
- 8030956087352
- Sales unit
- pcs
- Voltage inputs
- 1-phase (2-wire), 220 V L-N; 1-phase (2-wire), 230 V L-N; 3-phase (4-wire), 220/380 V; 3-phase (4-wire), 230/400 V; 3-phase (3-wire), 240 V L-L; 3-phase (3-wire), 380 V L-L; 3-phase (3-wire), 400 V L-L
- Frequency
- 50Hz
- Current inputs
- direct connection up to 65 A
- Energy metering
- Consumption
- Communication port and protocol
- wireless M-Bus with embedded antenna
- Power supply
- Self power supply
- Approvals, marks, declarations
- CE (Europe); MID (Europe, fiscal metering); UKCA (UK)
- E-number (NO)
- 8200717
- E-number (SE)
- 0902421
- Mounting method
- DRA (DIN-rail adaptor)
- Model
- Direct measurement
- Suitable for
- Purchase
- Type of indication
- Digital
- Max. current (Imax)
- 65 A
- Width in number of modular spacings
- 4
- Number of positions total (counter)
- 8
- Type of meter
- Electronic
- Degree of protection (IP)
- IP50
- Type of interface
- M-bus (wired)
- Energy type
- Effective power and reactive power
- Tariff type
- Multi-tariff
- Tariff control
- External
- Escapement mechanism
- No
- Calibrated
- Yes
- Approval
- Measuring Instruments Directive
- Pulse output
- Optical
- Accuracy class
- B
- Pole type
- Three conductor/four conductor
- Measurement type load profile
- No
- EEC40 signature
- No
- With lock code
- Yes
- Nominal voltage (Un) N-L
- 120–277 V
- Nominal voltage (Un) L-L
- 208–480 V
- Nominal current (In)
- 10 A
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 9031.80
Cross References
- EAN 8030956087352
- SAP 1200453775
- Code 82514957
Product Documentation
More from Carlo Gavazzi
Carlo Gavazzi
Meter Wireless MBUS EXT ANT (EM24DINAV53XW1EPFB)
Carlo Gavazzi
Inductive Transmitter ICB18S30F05PO
Carlo Gavazzi
Auxiliary Relay 11-Pin 110VDC
RCP11003110VDC
Carlo Gavazzi
IND Transmitter M30 NPN NC Shielded 2M Cable
ICS30L50F15NCB2E1
Carlo Gavazzi
Wireless receiver for LORA
UWPMM1UL1X
Carlo Gavazzi
Inductive transmitter M18, long, NPN NC, plug
ICS18L50F08NCM1E1
Carlo Gavazzi
SSR 3-F. 600VAC/55A 24-275VAC (RZ3A60A55P)
Carlo Gavazzi
Three-Phase Energy Transducer 3×20 mA DC Output
