Carlo Gavazzi 92555 Ceiling Flush-Mount Presence Detector 360 Degree PIR
Pricing
Request a quote
We reply within 24 hours
Product Description
Carlo Gavazzi 92555 is a flush-mounted ceiling presence detector for standard wall boxes, with a single potential-free output. 360 degree passive-infrared sensor with 5 m frontal and sideways reach and up to 78 m2 detection area at 2.5 m mounting height. Rated 230 V AC, IP20, with switching capacity up to 2300 W (10 W LED).
Technical Specifications
- Manufacturer part number (MPN)
- 92555
- EAN / GTIN
- 4007529925551
- Sales unit
- pcs
- Nominal voltage
- 230 V
- Mounting method
- Flush-mounted
- Colour
- White
- Model
- Movement sensor
- Height
- 65 mm
- Connection type
- Screwed terminal
- Surface protection
- Untreated
- Voltage type
- AC
- Switching-on delay
- 1 s
- Switch-off delay
- 1 s
- Built-in depth
- 65 mm
- Diameter
- 88 mm
- Material quality
- Thermoplastic
- Max. reach frontally
- 5 m
- Max. reach sideways
- 5 m
- Max. switching power
- 2300 W
- Temperature
- -25–50 °C
- Max. starting current
- 165 A
- Material
- Plastic
- Diameter reach on floor
- 10 m
- RAL-number (similar)
- 9010
- Control current
- 17 mA
- Scan angle
- 360 °
- Impact strength
- IK00
- Degree of protection (IP)
- IP20
- Surface finishing
- Matt
- Min. switch-on time
- 1 s
- Max. duty cycle
- 30 min
- Suitable for wall mounting
- No
- Optimum mounting height
- 2.5 m
- Number of switching zones
- 3
- With DALI interface
- No
- Min. starting current
- 0 A
- Min. depth of built-in installation box
- 50 mm
- Max. presence range
- 78 m²
- Max. switching power LED
- 10 W
- Sensor type
- Passive infrared
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8535.90
Cross References
- EAN 4007529925551
- SAP 1000515983
- Code 8814478
Product Documentation
More from Carlo Gavazzi
Carlo Gavazzi
SMH Thermostat universal
SHE5XTEMDIS
Carlo Gavazzi
SSR 230VAC/25A 3-32VDC
RM1A23D25
Carlo Gavazzi
Inductive transmitter M18 PNP NO plug connection (ICB18L50F12POM1)
Carlo Gavazzi
Power supply 240W 24VDC
SPDM242401
Carlo Gavazzi
M12 Capacitive transmitter IO-Link M12 plug (CA12EAN08BPM1IO)
Carlo Gavazzi
SMB sensor temp+CO2 (SHSUCOT)
Carlo Gavazzi
SSR 400VAC/50A 4-20MA
RM1E40AA50
Carlo Gavazzi
Split-core current transformer 1250 (CTD8S12505AXXX)
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 92555?
- 92555 can be ordered from cballast.com as a Carlo Gavazzi catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Carlo Gavazzi product?
- The manufacturer part number is 92555.
- What is the HS code for 92555?
- The customs tariff (HS) code for 92555 is 8535.90.
- Who manufactures 92555?
- 92555 is a Carlo Gavazzi product in the Lighting & Electrical Accessories range.
- Is a datasheet available for 92555?
- Yes — the 92555 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 92555?
- The minimum order quantity is 1.
- Is 92555 available?
- Yes — 92555 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
