Product Description
Generic TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR Fixed cargo-tank cleaning machine for crude-oil washing, chemical, product and slop-tank wash on tanker, bulker and FPSO duty. Used across marine engine-room, cargo transfer, ballast, bilge, cooling and process fluid transfer duty.
Technical Specifications
- Type
- fixed cargo-tank cleaning machine Drive: water-driven turbine Jet configuration: twin 32 mm nozzles Effective cleaning radius: 70 m radius Nozzle material: phosphor bronze / 316L (model-dependent) Body: cast bronze CC491K or 316L stainless Operating pressure: 4-16 bar (see model) Water temperature: max 95 °C Cycle time: 1.5 to 8 minutes per full sphere Inlet: ANSI Class 150 / EN 1092-1 PN16 flanged or BSP F threaded Deck-penetration kit: optional with double-block ball valve Approvals: USCG / IMO MEPC.1/Circ.677 COW machine type approval (model-dependent) Nominal diameter: DN100
Standards & Compliance
- Material
- Bronze CC491K / 316L stainless (model-dependent)
- HS Code
- 8424.89
Compatibility & Fitment
Form-fit envelope of Butterworth K, SA & SAT series, Toftejorg TZ-74 / TJ-20 / SaniMagnum / SaniMega, Scanjet Marine SC / SM, Alfa Laval Toftejorg, Gunclean Toftejorg TJ-LV, Lamor LSC and Mol-Dan tank-cleaning machines. Drop-in on the same flange face with matching deck-penetration sleeve. Genuine OEM machines available on request; this is the verified-compatible equivalent.
Product Documentation
More from Generic
Generic
Cargo-Tank Cleaning Machine — Portable DN50 Bronze 5-bar 60 °C
TCM-PORTABLE-DN50-BRONZE-5-BAR-60-C
Generic
Cargo-Tank Cleaning Machine — Portable DN65 SS316 10-bar 95 °C
TCM-PORTABLE-DN65-SS316-10-BAR-95-C
Generic
Cargo-Tank Cleaning Machine — Programmable Tank Cleaner DN65 SS316 10-bar
TCM-PROGRAMMABLE-TANK-CLEANER-DN65-SS316-10-
Generic
Cargo-Tank Cleaning Machine — Crude-Oil-Washing (COW) Machine DN150 SS316
TCM-CRUDE-OIL-WASHING-COW-MACHINE-DN150-SS31
Generic
15 ppm Bilge Oily-Water Separator 0.10 m³/h — IMO MEPC.107(49)
OWS-010MH-15PPM
Generic
15 ppm Bilge Oily-Water Separator 0.25 m³/h — IMO MEPC.107(49)
OWS-025MH-15PPM
Generic
15 ppm Bilge Oily-Water Separator 0.50 m³/h — IMO MEPC.107(49)
OWS-050MH-15PPM
Generic
15 ppm Bilge Oily-Water Separator 1.00 m³/h — IMO MEPC.107(49)
OWS-100MH-15PPM
Catalogue entry last verified: 2026-08-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR?
- TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR can be ordered from cballast.com: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this product?
- The manufacturer part number is TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR.
- What is the HS code for TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR?
- The customs tariff (HS) code for TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR is 8424.89.
- Is a datasheet available for TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR?
- Yes — the TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR?
- The minimum order quantity is 1.
- Is TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR available?
- Yes — TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
- How do I get a price for TCM-FIXED-TWIN-NOZZLE-DN100-SS316-12-BAR?
- Request a quotation with the quote button on this page or by email to sales@cballast.com — we reply within 24 hours with price, availability and lead time.
