Product Description
The electrical rotary actuator Type 3004 is a compact, powerful and explosion-proof actuator system with a long service life. Materials and components have been chosen for a maintenance-free operation and ensure low thermal loading on the actuator. The modular design offers many options such as extra limit switches or potentiometers to be added to the basic unit.
Technical Specifications
- Cover
- Epoxy-coated aluminium
- Body
- Epoxy-coated aluminium
- Axis
- Stainless steel
- Screws
- Stainless steel
- Gear
- Stainless steel
- Motor 25, 45, 75 Nm
- 4 kg
- Motor 100, 150, 300 Nm
- 6 kg
- Torque
- 25, 45, 75, 100, 150, 300 Nm
- Rotation angle
- 90° (± 5°) (special angles on request)
- Options
- Rotation angle 180° or 270°
- Operating voltage
- 100…240 V AC / 50…60 Hz or 24 V AC/DC ± 10 %
- Power consumption
- 45…85 W
- Voltage tolerance
- ± 10 %
- Input
- 0…10 V / 4…20 mA / 0…20 mA
- Output
- 0…10 V / 4…20 mA / 0…20 mA
Standards & Compliance
- HS Code
- 8481.80
Cross References
- Burkert 3004
- Buerkert 3004
- Bürkert 3004
- Type 3004
- Burkert Type 3004
Product Documentation
