Abiko A 0525 SK Insulated Butt Splice Connector 0.5 mm² Red
Pricing
Request a quote
We reply within 24 hours
Product Description
Abiko A 0525 SK insulated butt splice connector for joining two conductors of 0.5 mm² cross-section. Tin-plated copper barrel; nylon (PA) insulation. Crimped and insulated with a colour-coded easy-entry nylon sleeve. Rated -25 °C to +105 °C, to DIN 46341 / IEC 60228.
Technical Specifications
- Type
- Insulated cable butt splice (joins two conductors of equal cross-section)
- Manufacturer part number (MPN)
- A 0525 SK
- EAN / GTIN
- 7070920009837
- Conductor cross-section
- 0.5 mm²
- Material
- Tin-plated copper barrel; nylon (PA) insulation
- Insulation
- Nylon (PA), colour-coded Red, easy-entry funnel
- Voltage rating
- 690 V (DNV tested)
- Operating temperature
- -25 °C to +105 °C
- Standard
- DIN 46341 / IEC 60228
- Approvals
- UL, DNV type-tested, RoHS, Halogen-free
- HS code
- 8536.90
Standards & Compliance
- Standard
- DIN 46341 / IEC 60228
- Material
- Tin-plated copper barrel; nylon (PA) insulation
- Temperature Range
- -25 °C to +105 °C
- Classification / Approval
- UL, DNV type-tested, RoHS, Halogen-free
- HS Code
- 8536.90
Cross References
- EAN 7070920009837
- SAP 1200075807
- Code 81923165
Product Documentation
