EFF.BR.4P T5N 630-Lsi In=630
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB Automasjon 1SDA054402R0001 Circuit breaker T5N 630 PR222DS/P-LSI In=630 4p F F.
Technical Specifications
- Manufacturer part number (MPN)
- 1SDA054402R0001
- EAN / GTIN
- 8015644555009
- HS code
- 8536.90
- Sales unit
- pcs
- Number of poles
- 4
- Rated permanent current Iu
- 630 A
- With integrated under voltage release
- No
- Overload release current setting
- 252–630 A
- Rated voltage
- 690 V
- Power loss
- 41 W
- Degree of protection (IP)
- IP20
- Position of connection for main current circuit
- Front side
- Motor drive integrated
- No
- Type of electrical connection of main circuit
- Bolt connection
- Type of control element
- Wing knob
- With switched-off indicator
- No
- Rated short-circuit breaking capacity Icu at 400 V, 50 Hz
- 36 kA
- Adjustment range short-term delayed short-circuit release
- 378–6300 A
- Adjustment range undelayed short-circuit release
- 945–5985 A
- Suitable for DIN rail (top hat rail) mounting
- No
- Integrated earth fault protection
- No
- Motor drive optional
- Yes
- Device construction
- Built-in device fixed built-in technique
- DIN rail (top hat rail) mounting optional
- No
- Complete device with protection unit
- Yes
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 8015644555009
- SAP 1000012607
- Code 8482151
Product Documentation
