ABB Automasjon
Circuit Breaker S202M-C 40
Part numberS202M-C40EAN / GTIN4016779550345HS code8536.90
Electrical Components
Miniature Circuit Breakers
MOQ:1
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB Automasjon S202M-C40 S202M, 2pol, 40A, C-characteristic.
Technical Specifications
- Manufacturer part number (MPN)
- S202M-C40
- EAN / GTIN
- 4016779550345
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Power loss
- 9.6 W
- Built-in depth
- 69 mm
- Release characteristic
- C
- Number of poles (total)
- 2
- Number of protected poles
- 2
- Rated current
- 40 A
- Rated voltage
- 400 V
- Rated insulation voltage Ui
- 440 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Frequency
- 50–60 Hz
- Current limiting class
- 3
- Concurrently switching neutral conductor
- No
- Overvoltage category
- 3
- Pollution degree
- 3
- Additional equipment possible
- Yes
- Width in number of modular spacings
- 2
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -25–55 °C
- Connectable conductor cross section multi-wired
- 0.75–25 mm²
- Connectable conductor cross section solid-core
- 0.75–35 mm²
- Explosion-proof
- No
- Flush-mounted installation
- No
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 4016779550345
- SAP 1000023876
- Code 8497906
Product Documentation
Document preview: Circuit Breaker S202M-C 40 (S202M-C40) — Specification sheet
