ABB SACE Tmax XT7H 800 Moulded-Case Circuit Breaker — Ekip M Touch LRIU IN800A, In=800 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT7H 800 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 800 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip M Touch LRIU In800A. Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100930R1, EAN 8056221009843, ABB/SAP material 1200638581, catalogue code 83054516.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT7 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT7H 800 Ekip M Touch LRIU In800A 3p FF
- ABB order code (MPN)
- 1SDA100930R1
- EAN / GTIN
- 8056221009843
- ABB / SAP material no.
- 1200638581
- Frame
- XT7 (800 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- Ekip M Touch LRIU In800A
- Rated uninterrupted current In
- 800 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221009843
- SAP 1200638581
- Code 83054516
Product Documentation
More from ABB
ABB
ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip Touch LSI, In=800 A, 4-Pole
1SDA101722R1
ABB
ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip G Dip LS/In IN1250, In=1250 A, 3-Pole
1SDA101476R1
ABB
ABB 1SDA066400R1 Undervoltage Release Wired 380...440V AC FOR C.BREAKER Fixed-PLUG-IN XT1..XT4
ABB
ABB 1SL0275A00 Metal BASE Plate WITH Holes-SIZE 1;METAL BASE Plate WITH Holes-SIZE 1
ABB
ABB SACE Tmax XT7H 1600 Moulded-Case Circuit Breaker — Ekip Dip LSI, In=1600 A, 3-Pole 1SDA101437R1
ABB
ABB S201M-D1 Miniature Circuit Breaker — 1P, Type D, 1 A, 10 kA 2CDS271001R0011
ABB
ABB S204M-K1 Miniature Circuit Breaker — 4P, Type K, 1 A, 10 kA 2CDS274061R0257
ABB
ABB SACE Tmax XT2L 160 Moulded-Case Circuit Breaker — Ekip In, In=160 A, 4-Pole
