ABB SACE Tmax XT5S 400 Moulded-Case Circuit Breaker — Ekip Dip LS/In, In=250 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT5S 400 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 250 A, 3-pole, F/F (front, fixed) terminals. Electronic trip unit Ekip Dip LS/In (L overload, S short-time-delay, I instantaneous protection). Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100422R1, EAN 8056221004992, ABB/SAP material 1200638180, catalogue code 83055716.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5S 400 Ekip Dip LS/In In=250 3p FF
- ABB order code (MPN)
- 1SDA100422R1
- EAN / GTIN
- 8056221004992
- ABB / SAP material no.
- 1200638180
- Frame
- XT5 (400 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- Ekip Dip LS/In
- Rated uninterrupted current In
- 250 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221004992
- SAP 1200638180
- Code 83055716
Product Documentation
More from ABB
ABB
OVR T2 80-275S P QS (2CTB815708R1200)
ABB
ABB S204M-C2 Miniature Circuit Breaker — 4P, Type C, 2 A, 10 kA
2CDS274061R0024
ABB
ABB 1SFA896216R1001 Connection kit for PSR30…PSR37 with MS165
ABB
ABB SACE Tmax XT2V 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=25 A, 4-Pole
1SDA068005R1
ABB
XT6 W FP 4P EF EF IEC/UL
1SDA104699R1
ABB
ABB 1SFA899002R1072 Terminal enlargement suitable for PSR60 … 105
ABB
ABB SACE Tmax XT2N 160 Moulded-Case Circuit Breaker — MF 1 Im=14, In=1 A, 3-Pole
1SDA067044R1
ABB
ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — TMD 2-20, In=2 A, 4-Pole
1SDA067562R1
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA100422R1?
- 1SDA100422R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA100422R1.
- What is the HS code for 1SDA100422R1?
- The customs tariff (HS) code for 1SDA100422R1 is 8536.20.
- Who manufactures 1SDA100422R1?
- 1SDA100422R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA100422R1?
- Yes — the 1SDA100422R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA100422R1?
- The minimum order quantity is 1.
- Is 1SDA100422R1 available?
- Yes — 1SDA100422R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
