Product Description
ABB SACE Tmax XT5N 630 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 500 A, 3-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMA 500-5000 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class N; rated ultimate short-circuit breaking capacity Icu = 36 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA100346R1, EAN 8056221004237, ABB/SAP material 1200638743, catalogue code 83053024.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT5 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT5N 630 TMA 500-5000 3p FF
- ABB order code (MPN)
- 1SDA100346R1
- EAN / GTIN
- 8056221004237
- ABB / SAP material no.
- 1200638743
- Frame
- XT5 (630 A frame)
- Breaking-capacity class
- N
- Rated ultimate breaking capacity Icu (415 V AC)
- 36 kA
- Trip unit
- TMA 500-5000
- Rated uninterrupted current In
- 500 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8056221004237
- SAP 1200638743
- Code 83053024
