ABB SACE Tmax XT2H 160 Moulded-Case Switch-Disconnector — 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2H 160 A frame moulded-case switch-disconnector (non-automatic isolating and switching duty, supplied without an overcurrent trip unit). 4-pole, F/F (front, fixed) terminals. Rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA068170R1, EAN 8015644020675, ABB/SAP material 1000486485, catalogue code 8247346.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case switch-disconnector, IEC 60947-2)
- Configuration
- XT2H 160 SWITCH UNIT 4p FF
- ABB order code (MPN)
- 1SDA068170R1
- EAN / GTIN
- 8015644020675
- ABB / SAP material no.
- 1000486485
- Frame
- XT2 (160 A frame)
- Trip unit
- none (switch-disconnector)
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.50
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.50
Cross References
- EAN 8015644020675
- SAP 1000486485
- Code 8247346
