ABB SACE Tmax XT2S 160 Moulded-Case Circuit Breaker — MA 100 Im=600, In=100 A, 3-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT2S 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 100 A, 3-pole, F/F (front, fixed) terminals. Magnetic-only trip unit MA 100 Im=600 (magnetic instantaneous short-circuit release, for motor protection). Breaking-capacity class S; rated ultimate short-circuit breaking capacity Icu = 50 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA067769R1, EAN 8015644016654, ABB/SAP material 1200637546, catalogue code 83051659.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT2S 160 MA 100 Im=600...1400 3p FF
- ABB order code (MPN)
- 1SDA067769R1
- EAN / GTIN
- 8015644016654
- ABB / SAP material no.
- 1200637546
- Frame
- XT2 (160 A frame)
- Breaking-capacity class
- S
- Rated ultimate breaking capacity Icu (415 V AC)
- 50 kA
- Trip unit
- MA 100 Im=600
- Rated uninterrupted current In
- 100 A
- Poles
- 3
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644016654
- SAP 1200637546
- Code 83051659
