ABB SACE Tmax XT1H 160 Moulded-Case Circuit Breaker — TMD 32-450, In=32 A, 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB SACE Tmax XT1H 160 A frame moulded-case circuit breaker (MCCB). Rated uninterrupted current In = 32 A, 4-pole, F/F (front, fixed) terminals. Thermomagnetic trip unit TMD 32-450 (adjustable thermal overload and magnetic short-circuit release). Breaking-capacity class H; rated ultimate short-circuit breaking capacity Icu = 70 kA at 415 V AC; rated operational voltage Ue 690 V AC. Conforms to IEC/EN 60947-2. ABB order code 1SDA080853R1, EAN 8015644873813, ABB/SAP material 1200637069, catalogue code 83055170.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT1 (moulded-case circuit breaker, IEC 60947-2)
- Configuration
- XT1H 160 TMD 32-450 4p FF
- ABB order code (MPN)
- 1SDA080853R1
- EAN / GTIN
- 8015644873813
- ABB / SAP material no.
- 1200637069
- Frame
- XT1 (160 A frame)
- Breaking-capacity class
- H
- Rated ultimate breaking capacity Icu (415 V AC)
- 70 kA
- Trip unit
- TMD 32-450
- Rated uninterrupted current In
- 32 A
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.20
- Sales unit
- pcs
Standards & Compliance
- Standard
- IEC/EN 60947-2
- HS Code
- 8536.20
Cross References
- EAN 8015644873813
- SAP 1200637069
- Code 83055170
Product Documentation
More from ABB
ABB
ABB 1SDA104795R1 2 Changeover Contact OPEN-Closed V < 400V AC-DC Wired FOR Fixed-PLUG-IN Circuit-Breaker XT5
ABB
Ekip LS/In In=63A XT4 4P
1SDA067519R1
ABB
Floor-Standing Cabinet TW412GB 1850X1050X350MM IP30
2CPX010394R9999
ABB
Undervoltagestrigger S2C-UA 110V AC
2CSS200911R0004
ABB
Ekip Touch LSI In=320 XT5 4P
1SDA100672R1
ABB
ABB 1SDA066265R1 Extended Front Terminals 4PCS FOR Fixed PART XT3
ABB
ABB SACE Tmax XT4S 160 Moulded-Case Circuit Breaker — Ekip LS/In, In=40 A, 4-Pole
1SDA068491R1
ABB
ABB 1SDA066606R1 KEY LOCK Ronis Equal Fellow A IN OPEN WITH KEY Withdrawable IN OPEN Position FOR C.BREAKER XT3
Catalogue entry last verified: 2026-09-29. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy 1SDA080853R1?
- 1SDA080853R1 can be ordered from cballast.com as a ABB catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this ABB product?
- The manufacturer part number is 1SDA080853R1.
- What is the HS code for 1SDA080853R1?
- The customs tariff (HS) code for 1SDA080853R1 is 8536.20.
- Who manufactures 1SDA080853R1?
- 1SDA080853R1 is a ABB product in the Electrical Components range.
- Is a datasheet available for 1SDA080853R1?
- Yes — the 1SDA080853R1 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for 1SDA080853R1?
- The minimum order quantity is 1.
- Is 1SDA080853R1 available?
- Yes — 1SDA080853R1 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
