ABB XT2S 160 MA 100A 3P 36KA
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 1SDA067851R1 SACE Tmax XT2S 160 3P 100A magnetic-only (MA) trip for motor feeder protection. 36kA at 400V. Paired with overload relay for complete motor protection. Installed as the primary motor branch-circuit protection device between the incoming feeder and the contactor.
Technical Specifications
- Material
- Glass-reinforced polyester housing
- Approval
- IEC 60947-2
- Standards
- IEC 60947-2
- Approvals
- CE
- HS code
- 8536.20
- Rated current
- 100 A
- Number of poles
- 3P
- Breaking capacity
- 36 kA
Standards & Compliance
- Material
- Glass-reinforced polyester housing
- Classification / Approval
- IEC 60947-2
- HS Code
- 8536.20
Product Documentation
