ABB SACE Tmax XT2V 160 Moulded-Case Switch-Disconnector — 4-Pole
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 1SDA068172R1 SACE Tmax XT4N 250 3P 160A frame with Ekip LSI electronic trip unit. L (long-time), S (short-time), I (instantaneous) protection. 36kA breaking at 400V. Installed as the primary motor branch-circuit protection device between the incoming feeder and the contactor.
Technical Specifications
- Manufacturer
- ABB
- Product family
- SACE Tmax XT2 (moulded-case switch-disconnector, IEC 60947-2)
- Configuration
- XT2V 160 SWITCH UNIT 4p FF
- ABB order code (MPN)
- 1SDA068172R1
- EAN / GTIN
- 8015644020699
- ABB / SAP material no.
- 1000486487
- Frame
- XT2 (160 A frame)
- Trip unit
- none (switch-disconnector)
- Poles
- 4
- Terminals
- F/F (front, fixed)
- Rated operational voltage Ue
- 690 V AC
- Standard
- IEC/EN 60947-2
- HS code
- 8536.50
- Sales unit
- pcs
Standards & Compliance
- Material
- Glass-reinforced polyester housing
- Classification / Approval
- IEC 60947-2
- HS Code
- 8536.20
Product Documentation
