Residual Current Circuit Breaker WITH Overcurrent DS201 M B6 A100MA
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 2CSR275180R2065 DS201 M B6 A100, 10kA, 2mod, B kar, 6A, 1 pole+N, 100mA.
Technical Specifications
- Manufacturer part number (MPN)
- 2CSR275180R2065
- EAN / GTIN
- 8012542562719
- HS code
- 8536.90
- Sales unit
- pcs
- Package quantity
- 5 pcs
- Power loss
- 2.6 W
- Number of poles (total)
- 2
- Number of protected poles
- 1
- Rated voltage
- 240 V
- Rated insulation voltage Ui
- 500 V
- Rated impulse withstand voltage Uimp
- 4 kV
- Rated current
- 6 A
- Rated fault current
- 0.1 A
- Leakage current type
- A
- Current limiting class
- 3
- Rated short-circuit breaking capacity according to EN 61009
- 10 kA
- Disconnection characteristic
- Undelayed
- Voltage type
- AC
- Release characteristic
- B
- Concurrently switching neutral conductor
- Yes
- With interlocking device
- No
- Overvoltage category
- 3
- Pollution degree
- 2
- Ambient temperature during operating
- -25–55 °C
- Width in number of modular spacings
- 2
- Built-in depth
- 69 mm
- Anti-nuisance tripping version
- No
- Degree of protection (IP)
- IP20
- Connectable conductor cross section multi-wired
- 0.75–16 mm²
- Flush-mounted installation
- No
- Mounting method
- DIN rail
- Country of origin
- Italy
Standards & Compliance
- HS Code
- 8536.90
Cross References
- EAN 8012542562719
- SAP 1200385252
- Code 82430888
Product Documentation
More from ABB
ABB
ABB 1SDA105020R1 LOW Terminal-Covers Three-POLE 2PCS XT6
ABB
ABB SACE Tmax XT4L 250 Moulded-Case Circuit Breaker — Ekip In, In=250 A, 3-Pole
1SDA068560R1
ABB
ABB 2CTB815708R3500 OVR T2 3L 80-440S P TS QS Surge Protective Device
ABB
Ekip G Dip LS/In In=800 3P XT6
1SDA100810R1
ABB
ABB 1SDA102024R1 Rating PLUG In=1250A XT7-XT7M EKIP DIP LSI-LSIG EKIP Touch + RC (INSTALL.) IEC
ABB
ABB 2CCA880220R0001 CMS-120CA 18mm Open-Core Sensor up to 80A
ABB
XT5 P FP 400A 4P HR HR IEC
1SDA104674R1
ABB
XT5 P FP 400A 4P frame configurable
