ABB DDA203 RCD Block — 3-Pole, Type A AP-R, 25 A, 30 mA, 230 V, for S200 MCB

The ABB 1653231 is a DDA203 residual current device (RCD) block from the DDA200 range. It assembles onto an ABB S200 series miniature circuit breaker and adds residual-current protection to that breaker's overcurrent protection, so earth-fault protection can be added to selected ways of a board without stocking a separate RCBO for every rating. It is 3-pole, rated 25 A at 230 V, with a rated residual current of 30 mA. Type A means it responds to sinusoidal AC and pulsating DC residual currents. At 30 mA it is rated for protection of people against electric shock, which is the sensitivity required for socket outlets and other circuits where direct contact is foreseeable. This is the AP-R high-immunity version, which trips with a short delay so that it rides through brief leakage surges from switching and from electronic equipment filters rather than nuisance-tripping on them. Supplied by cBallast on quote-to-invoice terms; lead time and freight are quoted per RFQ against the destination Incoterm.

Manufacturer part number (MPN)

1653231

Sales unit

pcs

El-nummer (NO)

1653231

ETIM class

SC002297

Voltage

230 V

Rated current

25 A

Power loss

9 W

Nominal voltage

230–400 V

Nominal current

25 A

Rated fault current adjustable

No

Rated fault current

0.03 A

Delay adjustable

No

Number of poles

3

Leakage current type

A

Surge current capacity

3 kA

Frequency

50/60 Hz

Rated insulation voltage Ui

500 V

Rated impulse withstand voltage Uimp

4 kV

Connectable conductor cross section solid-core

16 mm²

Connectable conductor cross section multi-wired

16 mm²

Anti-nuisance tripping version

Yes

With interlocking device

Yes

Degree of protection (IP)

IP2X

Pollution degree

2

Ambient temperature during operating

-25–55 °C

Country of origin

Italy

Product family

ABB DDA200 RCD block (System pro M compact)

Device type

Add-on residual current device (RCD) block for MCB

Model

DDA203

Rated residual current (IΔn)

30 mA

Suitable for

ABB S200 series miniature circuit breakers

Tripping characteristic

AP-R — high immunity, short delay

Protection purpose

Protection of people against electric shock

HS Code

8536.20

• 8012542750338
• El-nr 1653231
• MPN 1653231
• Model DDA203
