FLEX Insert 230V (64891 U-500)
Pricing
Request a quote
We reply within 24 hours
Product Description
ABB 64891 U-500 — 3 wire connection (neutral conductor required). For the extension of the ABB Comfort switch, ABB Watchdog or ABB presence detector installations.For group control of flex inserts via extension unit communication.Operation in 1gang 2way installations via push button input. Without control unit. For control element flex, 1gang, 64711-500. For control element flex, 1gang, wireless, 62711-WL-500. For control element flex, 2gang, 64721-500. For control element flex, 2gang, wireless, 62721-WL-500. For ABB Comfort switch flex control element 64765-…-500.For ABB Watchdog 180 flex sensors 6476x-…-500.For ABB Watchdog 180 flex sensors, wireless, 6276x-.-WL-500. For ABB presence detector flex sensors 6475x-…-500.Combinable with all flex inserts.
Technical Specifications
- Manufacturer part number (MPN)
- 64891 U-500
- EAN / GTIN
- 4011395294116
- Sales unit
- pcs
- Voltage
- 230 V
- Instructions and Manuals
- 2CKA000073B5103; 2CKA000073B5132; 2CKA000073B5133; 2CKA000073B5134
- Instructions and Manuals (Part 2)
- 2CKA000073B5216
- Mounting Type
- Flush Mounted
- Type of Fastening
- Mounting with Screw; Mounting with Claw
- Modular Components Included
- Flush Mounted Insert with Mounting Plate
- Ambient Air Temperature
- Operation -5 ... +45 °C
- Degree of Protection
- IP20
- Number of Outputs
- 1
- Product Range
- flexTronics; flexTronics wireless; free@home wireless; free@home
- Connection Type
- Pin
- Terminal Type
- Screw Terminals
- Rated Voltage (U r )
- 230 V
- Rated Frequency (f)
- 50 Hz
- Power Loss
- 0.3 W; Total 0 W
- Design Range
- Platform 63; Busch-balance SI; Reflex SI; Busch-Duro 2000 SI; Busch-art linear; future linear; Busch-axcent; Pure Stainless Steel; solo; carat; Busch-Dynasty; Trevion
- Design Range Variant
- Busch-Duro 2000 SI; Busch-Duro 2000 SI Linear; Reflex SI; Reflex SI Linear; Busch-art linear; Busch-art linear - with Decor Ring; Busch-art linear - pur; future; future linear; Busch-axcent; Busch-axcent pur
- Product Net Width
- 0.14 m
- Product Net Height
- 0.227 m
- Product Net Depth / Length
- 0.181 m
- Built-In Depth ( t 2 )
- 25 mm
- Building Information Modeling – BIM
- 9AKK108471A9951
- Environmental Product Declaration - EPD
- 9AKK108469A3355
- Declaration of Conformity - CE
- 2CKA100000E4339
- EU Data Act Compliance Declaration
- 9AKK108471A4355
- EU Data Act Applicability and Compliance
- Applicable - Compliant
- ETIM 9
- EC001588 - Electronic switch
- eClass
- V11.0 : 27144054
- Assembly arrangement
- Basic element
- Model
- Substation
- Substation input
- Yes
- Light value memory
- Yes
- Applicable with button
- Yes
- Applicable with movement sensor
- Yes
- Applicable with presence indicator
- Yes
- Applicable with time switch/timer
- Yes
- Applicable with transmission button
- Yes
- Applicable with infrared button
- Yes
- Mounting method
- Flush-mounted
- Material
- Plastic
- Surface protection
- Galvanised
- Surface finishing
- Glossy
- Colour
- Black
- RAL-number (similar)
- 9005
- Transparent
- Yes
- Nominal voltage
- 230 V
- Frequency
- 50 Hz
- Min. depth of built-in installation box
- 25 mm
- Compatible with Apple HomeKit
- Yes
- Compatible with Google Assistant
- Yes
- Compatible with Amazon Alexa
- Yes
- IFTTT support available
- Yes
- Country of origin
- Germany
Standards & Compliance
- HS Code
- 8538.90
Cross References
- EAN 4011395294116
- SAP 1200681861
- Code 83539771
Product Documentation
