Weld flange with collar acid-resistant - 16", 150LBS, 40S, 406,4mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Weld flange with collar acid-resistant. Welding flanges ASTM (Technique / Acid-resistant and Stainless fittings / Flanger). Principal data: dimension 16", pressure ansi 150 Lbs, sch-class 40S, for pipes with outer diameter 406.4 mm. Supplied under manufacturer part number FW10229086, HS code 7307.21, country of origin India.
Technical Specifications
- Product type
- Welding flanges ASTM Product group: Acid-resistant and Stainless fittings Dimension: 16" Pressure ANSI: 150 Lbs SCH-class: 40S For pipes with outer diameter: 406.4 mm Number of bolt holes: 16 pcs Bolt hole diameter: 28.6 mm Bolt circle diameter: 539 mm Flange thickness: 35 mm Diameter: 595 mm Steel quality: 316/316L Tolerance: A-182 WN/RF , SF material certificate: EN 10204 3.1 Weight: 62.55 kg X dimension: 457 mm R dimension: 469.9 mm Y dimension: 125 mm Rf dimension: 2 mm REACH SVHC substance above 0.1%: None Carbon footprint (EPD): 0.1739 kg CO2e per pcs Environmental declaration: LCA Country of origin: India Customs tariff code (EU CN): 73072100 HS code: 7307.21 Manufacturer part number: FW10229086
Standards & Compliance
- HS Code
- 7307.21
Cross References
- MPN FW10229086
Product Documentation
More from Generic
Generic
Round steel stainless centerless-ground EN 4057 H9 - 16mm, 3M, 1.58KG/m
5300160003
Generic
DIN 931 Hex Bolt 10.9 Untreated M10x80 mm, 50-pack
10931100801
Generic
DIN 912 Allen Screw MF Cylindrical Black 12.9 - M24, 80mm, 25PCS
12912MF242000801
Generic
ISO 4017 / DIN 933 Set Screw acid-resistant A4 KL. 70 - M16, 80mm, 25PCS
933160806
Generic
Flat steel S355J2 - 150mm, 18.041KG/m, 15mm, 6.1M
42015
Generic
Clamp Band - 68mm, 85mm, 12mm, acid-resistant W5
G5068
Generic
Brass Rod brass round CW614N/MS 58 - 85mm, 3000mm, 48.2KG/m
1059563
Generic
DIN 988 Shim Washer black black - 5mm, 10mm, 1mm, 100PCS
9880501001
Catalogue entry last verified: 2026-09-30. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy FW10229086?
- FW10229086 can be ordered from cballast.com: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this product?
- The manufacturer part number is FW10229086.
- What is the HS code for FW10229086?
- The customs tariff (HS) code for FW10229086 is 7307.21.
- Is a datasheet available for FW10229086?
- Yes — the FW10229086 datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for FW10229086?
- The minimum order quantity is 1.
- Is FW10229086 available?
- Yes — FW10229086 is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
- How do I get a price for FW10229086?
- Request a quotation with the quote button on this page or by email to sales@cballast.com — we reply within 24 hours with price, availability and lead time.
