Weld flange flat stainless - 500, 508mm, 10bar
Pricing
Request a quote
We reply within 24 hours
Product Description
Weld flange flat stainless. Welding flanges DIN/ISO (Technique / Acid-resistant and Stainless fittings / Flanger). Principal data: dn dimension 500, for pipes with outer diameter 508 mm, pressure pn 10 bar. Supplied under manufacturer part number GS13089244, HS code 7307.21, country of origin India.
Technical Specifications
- Product type
- Welding flanges DIN/ISO
- Product group
- Acid-resistant and Stainless fittings
- DN dimension
- 500
- For pipes with outer diameter
- 508 mm
- Pressure PN
- 10 bar
- Number of bolt holes
- 20 pcs
- Bolt hole diameter
- 26 mm
- Bolt dimension
- 24 mm
- Bolt circle diameter
- 620 mm
- Flange thickness
- 38 mm
- Diameter
- 670 mm
- Material certificate
- EN 10204 3.1
- Inner diameter
- 513.5 mm
- Steel quality
- 4301/4307
- Tolerance
- EN-1092 type 01A
- Weight
- 40.2 kg
- REACH SVHC substance above 0.1%
- None
- Carbon footprint (EPD)
- 0.1118 kg CO2e per pcs
- Environmental declaration
- LCA
- Country of origin
- India
- Customs tariff code (EU CN)
- 73072100
- HS code
- 7307.21
- Manufacturer part number
- GS13089244
Standards & Compliance
- HS Code
- 7307.21
Cross References
- MPN GS13089244
Product Documentation
