Weld flange flat acid-resistant - 1 1/2", 300LBS, 48,3mm
Pricing
Request a quote
We reply within 24 hours
Product Description
Weld flange flat acid-resistant. Welding flanges ASTM (Technique / Acid-resistant and Stainless fittings / Flanger). Principal data: dimension 1 1/2", pressure ansi 300 Lbs, for pipes with outer diameter 48.3 mm. Supplied under manufacturer part number FS15224500, HS code 7307.21, country of origin India.
Technical Specifications
- Product type
- Welding flanges ASTM Product group: Acid-resistant and Stainless fittings Dimension: 1 1/2" Pressure ANSI: 300 Lbs For pipes with outer diameter: 48.3 mm Number of bolt holes: 4 pcs Bolt hole diameter: 22.2 mm Bolt circle diameter: 114 mm Flange thickness: 19.1 mm Diameter: 155 mm Steel quality: 316/316L Tolerance: A-182 SO/RF , SF material certificate: EN 10204 3.1 Weight: 2.51 kg X dimension: 70 mm R dimension: 73 mm Y dimension: 29 mm Rf dimension: 2 mm REACH SVHC substance above 0.1%: None Carbon footprint (EPD): 0.0070 kg CO2e per pcs Environmental declaration: LCA Country of origin: India Customs tariff code (EU CN): 73072100 HS code: 7307.21 Manufacturer part number: FS15224500
Standards & Compliance
- HS Code
- 7307.21
Cross References
- MPN FS15224500
Product Documentation
