Wallace & Tiernan Quartz Sleeve, WTL 2000, 410 mm, Part AAC6187

Quartz sleeve for the Wallace & Tiernan WTL 2000 UV disinfection system, original part number AAC6187. It measures 410 mm long by 33 mm in diameter. A quartz sleeve is the transparent tube that separates the UV lamp from the water: the lamp runs dry inside it while the flow passes outside, and the quartz transmits the 254 nm germicidal output that ordinary glass would absorb. It is a wear part rather than a fitting — it fouls with scale and film, which cuts UV transmittance and therefore delivered dose long before anything looks wrong, and it becomes fragile with thermal and mechanical stress. Clean it on schedule and renew it when cleaning no longer restores transmittance, or when it is chipped, etched or cracked. The same sleeve is listed against the Wallace & Tiernan M135, Barrier M80, M275 and M1250 units, so one part covers several reactors across the range. Wallace & Tiernan is an Evoqua Water Technologies brand, and was part of Siemens Water Technologies before that, so the same equipment is catalogued under all three names and its parts carry Evoqua W3T/W2T and legacy AAC/AAD numbers. Item number 4102-0508. Original part number AAC6187. Supplied by cBallast on quote-to-invoice terms; lead time and freight are quoted per RFQ against the destination Incoterm.

Part type

Quartz sleeve

Original part number

AAC6187

Overall length

410 mm

Diameter

33 mm

Material

Quartz

Compatible systems

Wallace & Tiernan WTL 2000, M135, Barrier M80, M275 (Siemens), M1250

Related item

4100-0707 — matching UV lamp for WTL 2000

HS code

7020.00

Material

Fused quartz (SiO2)

HS Code

7020.00

• Article 4102-0508
• Wallace & Tiernan AAC6187
• Evoqua Wallace & Tiernan WTL 2000
