Telemecanique XUAH0525S Miniature Photoelectric Sensor M8, Diffuse, PNP NC, M8 Connector
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XUAH0525S miniature photoelectric sensor, diffuse, M8 metal body, PNP NC output, M8 connector.
Technical Specifications
- Manufacturer part number (MPN)
- XUAH0525S
- EAN / GTIN
- 3666916036877
- Sales unit
- pcs
- Package quantity
- 10 pcs
- Thread size
- M8
- Voltage type
- AC/DC
- Max. output current
- 100 mA
- Housing material
- Metal
- Suitable for safety functions
- No
- Ambient temperature
- -25–55 °C
- With time function
- No
- Switching frequency
- 1000 Hz
- Number of semiconductor outputs with signalling function
- 1
- Number of protected semiconductor outputs
- 1
- Type of electric connection
- Connector M8
- Type of switching output
- PNP/PNP
- Type of switch function
- Breaker contact (NC)
- Rated control supply voltage DC
- 12–24 V
- Operation agent-safety class
- Safety class 0
- Explosion safety category for gas
- None
- Explosion safety category for dust
- None
- Construction type housing
- Cylinder, screw-thread
- Laser protection class
- None
- Type of light
- Infrared light
- Max. output current at protected output
- 100 mA
- Min. reflector distance
- 0 mm
- With monitoring function downstream switching devices
- No
- With restart blockage
- No
- Response time
- 0.5 ms
- Transmission range of the safety field
- 3 m
- Type of safety according to IEC 61496-1
- 1
- Pre failure notice
- No
- Material of optical surface
- Plastic
- Degree of protection (IP)
- IP65
- Analogue output 0 V ... 10 V
- No
- Analogue output 0 mA ... 20 mA
- No
- Analogue output -10 V ... +10 V
- No
- Analogue output 4 mA ... 20 mA
- No
- Diameter sensor
- 8 mm
- With communication interface analogue
- No
- With communication interface AS-Interface
- No
- With communication interface CANOpen
- No
- With communication interface DeviceNet
- No
- With communication interface Ethernet
- No
- With communication interface INTERBUS
- No
- With communication interface PROFIBUS
- No
- With communication interface RS-232
- No
- With communication interface RS-422
- No
- With communication interface RS-485
- No
- With communication interface SSD
- No
- With communication interface SSI
- No
- Length of sensor
- 47 mm
- Max. switching distance
- 60 mm
- With reflector
- No
- With other analogue output
- No
- Sensing mode
- Light switching
- Country of origin
- France
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916036877
- SAP 1000342058
- Code 82037230
Product Documentation
More from Telemecanique
Telemecanique
Telemecanique XUSL4MB40H091N Type 4 Safety Light Grille with Integrated Muting, 910 mm protected height
Telemecanique
Telemecanique OsiSense XS7E1A1PAM8 Inductive Proximity Sensor — 26 × 26 mm block, Sn 10 mm, PNP, NO, M8 connector
Telemecanique
Photocell colour kontr. NPN M12
XUKR1NSMM12
Telemecanique
Telemecanique XXR18A3KAM12 Ultrasonic Sensor (Through-Beam Receiver) M18, PNP/NPN selectable, NO, M12 connector
Telemecanique
Telemecanique XMLR040G1N26 Pressure Sensor with Display, 0–40 bar, 4–20 mA + 1× NPN
Telemecanique
Limit SWITCH,METAL 2 POLE Nc+no (XCRB15)
Telemecanique
Telemecanique ZCKJ11H29 Limit Switch Body, Metal, NO+NC, Snap-action, Plug-In, M20 cable entry
Telemecanique
Telemecanique XZCPV1965L2 Sensor Cable, M8 female angled, 3-pin, PVC, 2 m
Technical guides
Catalogue entry last verified: 2026-10-03. A manufacturer datasheet is attached to this entry — confirm application-critical values against it.
Frequently asked questions
- Where can I buy XUAH0525S?
- XUAH0525S can be ordered from cballast.com as a Telemecanique catalogue item: request a quotation on this page or email sales@cballast.com, and the order ships worldwide.
- What is the manufacturer part number for this Telemecanique product?
- The manufacturer part number is XUAH0525S.
- What is the HS code for XUAH0525S?
- The customs tariff (HS) code for XUAH0525S is 8536.50.
- Who manufactures XUAH0525S?
- XUAH0525S is a Telemecanique product in the Sensors & Instrumentation range.
- Is a datasheet available for XUAH0525S?
- Yes — the XUAH0525S datasheet can be viewed and downloaded on this page.
- What is the minimum order quantity for XUAH0525S?
- The minimum order quantity is 1.
- Is XUAH0525S available?
- Yes — XUAH0525S is available to order: fulfilment is from supplier stock in cBallast's European network, dispatched directly from the warehouse to the customer, with the exact lead time stated in the quotation (reply within 24 hours).
