Telemecanique XCSLF3838512 Safety Door Interlock 24 V Metal 3NC+3NC
Pricing
Request a quote
We reply within 24 hours
Product Description
Telemecanique XCSLF3838512 is a mechanical safety interlock switch in a metal housing for guard-locking applications, operating on 24 V with a 3 NC + 3 NC contact configuration on slow-action contacts. Guard locking follows the quiescent current principle with a 20 N locking force and IP67K protection, and status indication is included. It uses metric cable entry and is intended for machinery safety functions on doors, gates and hatches.
Technical Specifications
- Manufacturer part number (MPN)
- XCSLF3838512
- EAN / GTIN
- 3666916047446
- Sales unit
- pcs
- Voltage
- 24 V
- Contact configuration
- 3 NC + 3 NC
- Type of locking
- Operating current principle
- Rated operation current Ie at AC-15, 230 V
- 0.75 A
- Housing material
- Metal
- Suitable for safety functions
- Yes
- With status indication
- Yes
- Type of switching contact
- Slow-action switch
- Type of interface for safety communication
- None
- Type of electric connection
- Cable entry metrical
- Explosion safety category for gas
- None
- Degree of protection (IP)
- IP67K
- Type of interface
- None
- Rated operation current Ie at DC-13, 24 V
- 0.55 A
- Width sensor
- 44 mm
- With escape release
- No
- Height of sensor
- 205 mm
- Length of sensor
- 51 mm
- Guard locking force
- 20 N
- Number of contacts as normally closed contact
- 3
- With auxiliary release
- No
- Type of guard locking
- Quiescent current principle
- Country of origin
- Indonesia
Standards & Compliance
- HS Code
- 8536.50
Cross References
- EAN 3666916047446
- SAP 1200328466
- Code 82319568
